13.56MHZ Desktop Usb Smart External Nfc Pay Card Reader Price

13.56MHZ Desktop Usb Smart External Nfc Pay Card Reader Price photo-1
13.56MHZ Desktop Usb Smart External Nfc Pay Card Reader Price photo-2
13.56MHZ Desktop Usb Smart External Nfc Pay Card Reader Price photo-3
13.56MHZ Desktop Usb Smart External Nfc Pay Card Reader Price photo-4
US$ 35 - 65 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
NFC reader
Model Number:
ACR_1255U
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name NFC reader
Model Number ACR_1255U
Product Description

13.56MHZ desktop usb smart external nfc pay card reader price

ACR1255U-J1 supports ISO 14443 Type A and B smart cards, MIFARE®, FeliCa®, and most NFC tags and devices compliant with ISO 18092 standard. This makes ACR1255U-J1 ideal for a broad range of solutions, such as hands-free verification for physical and logical access control, and inventory tracking. ACR1255U-J1 has two interfaces: Bluetooth Smart (also known as Bluetooth Low Energy or BLE) for pairing with mobile devices, and USB Full Speed for PC-linked operation. Additionally, it can read/write at a speed of up to 424 Kbps for contactless smart card and NFC device access.

With a compact design and a rechargeable Lithium-ion battery for power, ACR1255U-J1 is extremely portable and convenient for use anytime, anywhere with most Bluetooth-enabled smartphones and tablets.

To save valuable cost and time, the firmware of ACR1255U-J1 could conveniently be upgraded on the field. This enables users to cope with the fast-changing technology for their applications, and suit different scenarios.

With Bluetooth Smart technology, ACR1255U-J1 easily connects wirelessly to any device running on Android™ 4.3 and later, iOS 5.0 and later, Windows® 7 and later, and Mac OS® 10.7 and later.

For PC-linked operation, ACR1255U-J1 could easily be installed for use with any personal computer running on Windows® operating system because it is PC/SC and CCID-compliant. Its drivers are also compatible with Linux® and Mac OS®.

With its numerous features, the ACR1255U-J1 is the perfect reader for your smart card solution.

Features

Bluetooth® Smart Interface
USB-Powered (PC-linked mode):
       USB 2.0 Full Speed Interface
      CCID Compliance
       Firmware Upgradeable
      Application Programming Interface:
             Supports PC/SC
             Supports CT-API (through wrapper on top of PC/SC)
Battery-Powered:
       Powered by a Lithium-ion battery (rechargeable through PC-linked mode)
Smart Card Reader:
       Built-in antenna for contactless tag access, with reading distance of up to 60 mm (depending on tag type)
      Supports ISO 14443 Part 4 Type A and B cards
      Supports MIFARE® and MIFARE® DESFire®
      Supports FeliCa®
      Supports ISO 18092 Tags (NFC Tags)
      Built-in anti-collision feature (only one tag is accessed at any time)
NFC Support:
      Card reader/writer mode
      Card emulation mode

specifications
Mode
ACR_1255U
Dimensions
85.0mm (L) x 54.0mm (W) x 10.8mm (H)
Interface
Bluetooth Smart / USB Full Speed
Operating Distance
Up TO 50mm(depends on the tage type)
Supply Voltage
Regulated 5V DC
Supply Current
200 mA(operating);50mA(standby);100mA(normal)
Operating Temperature
0 - 50℃
Operating Frequency
13.56Mhz
Smart Card Interface Support
ISO14443 Type A&B;Mifare;Felica;4 types of NFC(ISO/IEC18092)tags
Compliance / Certifications
ISO 18092,ISO14443,CE,FCC,KC,RoHS 2


Operating System Support
Windows®
Linux®
Mac OS®
Android™
iOS 5.0 and above
