Portable USB NFC Long Distance Contactless Smart Card Reader and Writer Price PC/S CCID or USB New Products 2016 Made in China

Portable USB NFC Long Distance Contactless Smart Card Reader and Writer Price PC/S CCID or USB New Products 2016 Made in China photo-1
Portable USB NFC Long Distance Contactless Smart Card Reader and Writer Price PC/S CCID or USB New Products 2016 Made in China photo-2
Portable USB NFC Long Distance Contactless Smart Card Reader and Writer Price PC/S CCID or USB New Products 2016 Made in China photo-3
US$ 28 - 33 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
portable nfc long distance reader
Model Number:
M88
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name portable nfc long distance reader
Model Number M88
Product Description

Portable USB NFC long distance reader contactless smart card reader and writer Price PC/S CCID or USB new products 2016 made in china

M88 is a non-contact technology based on the development of the 13.56Mhz online non-contact smart card reader. As a global accord with CCID interface standard for contactless reader, it can meet the iso14443 and iso18092 requirements and supports both read and write Mifare card and iso14443 of class A and class B card, also supports felica card and an NFC tag.

M88 reads the speed of NFC tags up to 12Mbps, while supporting the USB 424Kbps full speed data transfer, and therefore can be a variety of contactless card / label for efficient read and write operations.

M88 also meet PS/SC standards, with a variety of applications and platforms to work with the ability to work.

M88 look simple and versatile, for payment, access control, attendance management, and public transportation and other applications can bring you a super convenient experience.
specifications
Mode
M88
Dimensions
120mm(L)x70mm(W)x18mm(H)
Material
ABS plastic shell
Interface
RS232/USB (HID, CCID)
Operating Distance
Up TO 50mm(depends on the tage type)
Supply Voltage
Regulated 5V DC
Supply Current
200 mA(operating);50mA(standby);100mA(normal)
Operating Temperature
-20℃ - 50℃
Operating Frequency
13.56Mhz
Smart Card Interface Support
ISO14443 Type A&B;Mifare;Felica;4 types of NFC(ISO/IEC18092)tags
Compliance / Certifications
ISO 18092,ISO14443,CE,FCC,KC,RoHS 2
Operating System Support
Windows 98, Me, 2K, XP, Vista and Unix, 2003 and Linux, Android
Our Company
Factory
Certifications
Packing & Delivery

Delivery

1. For small quantity parcel, we use the express couriers such as DHL, TNT, UPS, FEDEX ETC for quick shipment. It normally takes around 3~5 working days to receive the shipment.

2. For larger quantity, we normally ship by air and it normally takes around 5~7 working days to receive the pracel.
