Kubota Mobile Light Tower
Specifications
Kubota mobile light tower1.Kubota engine
2.Silent type, water cooled
3.9m mast
4.Protection system
| Model RPLT6000 | |
| Technical Specifications | |
| Mast | |
| Maximum extention of mast | 9m |
| Elevation | Mechanical |
| Raising/lowing mast | Winch(Mechanical) |
| Stages | 3 |
| Turning angle | 358 degrees non-continuous |
| Lamp | |
| Total power of lamps | 4×1000W |
| Type of lamp | Metal halide lamp |
| Light capacity | 4×110,000 lumen |
| Voltage | 230 or 240 |
| Frequency | 50Hz/60Hz |
| Lifetime of lamp | 5000hours |
| Working temperature | ≤85°C |
| Connection Protection index | IP54 |
| Light Coverage | 5 to 7 acres |
| Characteristics of the generator | |
| Model | RD-10 |
| Generator set Prime power | 50Hz 6.7kW / 60Hz 8.4kW |
| Engine model | Japan KUBOTA D1105-BG / UK PERKINS 403D-11G |
| Engine speed | 50Hz 1500rpm / 50Hz 1800rpm |
| Engine type | 3 cylinder,in line,water-cooled |
| Engine Aspiration | Natural |
| Alternator | STAMFORD PI 044F |
| Alternator Type | 4-pole, brushless |
| Fuel tank capacity | 70 L |
| Prime fuel consumption at 100% load | 2.0L/h |
| Working hours | 25 |
| Control system | GU602A Digital controller |
| Power Outlets | 2 |
| Trailer | |
| Tow hitch | Ring or ball hitch |
| Stabilier Supports | 5 × Manual |
| Tire Size | 52 cm |
| Anti-wind capacity | ≤10 |
| Brakes | Manual |
| Packing Dimension & Weight | |
| Retracted Dimension | 4400mm × 1350mm × 1930mm(Around) |
| Mast Packing | 3800mm ×350mm ×350mm (Around) |
| Generator set packing | 1550mm ×1150mm ×1610mm (Around) |
| 1000W lamps packing | 4 pcs 520mm ×520mm ×370mm (Around) |
| Container load (40HQ) | 6 |
| Net weight | 870kg |
