Lighting tower with 4 metal halide lamp

MOBILE LIGHT TOWER SERIES

Technical specifications

Mast

Maximum height of mast

9m

Elevation

Mechanical / Electric

Raising/lowering mast

Winch / Button

Turning angle

358 degrees

Stage

3

Lamps

Total power of lamps

4x1,000Watts

Type of lamp

Metal halide

Light capacity

4x88,000lumen

Voltages

120, 220, 230, 240Volts

Frequency

50Hz / 60Hz

Lifetime of lamp

5,000hours

Working temperature

≤85°C

Protection grade

IP54

Characteristics of generator set

Model

RPD6500I

Rated power

4.2kw/50Hz   5.0kw/60Hz

Engine model

RP186FA Diesel

Intake system

Natural Aspiration

Engine speed

50Hz 3000rpm,60Hz 3600rpm

Type

Single cylinder, air-cooled

Starting system

Electric

Alternator

2-pole, brushless

Fuel tank capacity

100L

Fuel consumption at 100% load

1.85L/H

Max continuous running time

60Hours

Control system

Digital control panel

Power Outlets

2

Trailer Type

Road trailer with hitch ball

Dimension (LXWXH) & Weight

Retracted Dimension

4400x1350x1930

Net weight

680kg
