RPLT1600A Portable Mobile Lamp

RPLT1600A Portable Mobile Lamp photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
RP186FA Diesel
Model Number:
RPLT1600A
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name RP186FA Diesel
Model Number RPLT1600A
Output Type AC Single Phase
Speed 50HZ 3000RPM 60HZ 3600RPM
Frequency 50HZ/60HZ
Rated Power 4.5KW/50HZ 5.0/60HZ
Rated Voltage 120V 220V 230V 240V

Specifications

Mast:4.8m(Mechanical/e)/Winch/358 degrees
Metal halide lamp/4x400Wt/220V
Ring or ball hitch
any size of lamps available

Model RPLT1600A
Technical Specifications
Mast
Maximum extention of mast 4.8m
Elevation Manual
Raising/lowing mast Winch(Mechanical)
Stages 2
Turning angle 358 degrees non-continuous
Lamp
Total power of lamps 4×400W
Type of lamp Metal halide lamp
Light capacity 4×25000 lumen
Frequency 50Hz
Working temperature ≤85Degrees Celsius
Connection Protection index IP54
Characteristics of the generator
Model RPD3500E(Made in China)
Generator set Prime power 50Hz 3.0kW
Engine model RP178F Diesel
Engine speed 50Hz 3000rpm
Engine type 1 cylinder,4-stroke,Air-cooled
Engine Aspiration Natural
Alternator Type 2-pole, brushless
Fuel tank capacity 12.5
Prime fuel consumption at 100% load 1.56L/h
Working hours 8
Control system Mechanical control panel
Power Outlets 2
Trailer
Stabilier Supports 4 × Manual
Anti-wind capacity ≤6
Brakes Manual
Packing Dimension & Weight
Retracted Dimension 1300mm × 840mm × 2600mm
Container load (20/40FT) 12/24(At least)
Net weight 270kg
