Specifications
1.Security 100%2.High oil yield 45%-55%
3.On-site guidence supported
4.1-2 years warranty
5.Life more than 5 years
WASTE PLASTIC, RUBBER, TIRE TO VALUABLE CRUDE OIL
WORKING PRINCIPLE: CATALYTIC PYROLYSIS, COOLING, SEDIMENTATION AND SPLIT-FLOW.
Main parameter of waste plastic oil refining equipment:
Designed pressure: 0.04(Mpa)
Designed temperature: 0-498(°C)
Volume: 30 (m3)
Application: Extract fuel oil
Special customizing: Yes
Weight: 32000 (kg)
Another name: Environmentally friendly waste plastic oil refining equipment
Model: WJ-8
Heat transfer area:46(m2)
working medium:ordinary pressure
The production line including following parts:
1. Reactor
2. Oil gas condenser system
3. Raw oil preheating system
4. Waste gas dispose and reburning system
5. The desulphurization and dedusting system
6. Pressure and temperature automatic control system
7. Automatic liquid feeding control system
8. Central control system
9. Residue discharging system
Unique characteristics:
1. The whole process of production is in smokeless environment, so the The effect of environmental
protection is very good.
2. High efficient gas heating system. During oil refining process, when the temperature of gas heated reach
150° there will produce plenty of gas which can not be liquefied like methane and butane. And These gas
can to recycled to burn in the specially designed gas nozzle to provide mount of heat, so it can replace parts
of coal fuel.
3. The whole equipment is installed with dust removal system, including de-sulphur dust collector and gas water tank to ensure the exhaust meet the national standard.
Pictures of main the whole production line
Reactor
The Innre durm of Reactor
FInal output: Crude Oil
The oil refined from the following tires
