Specifications
1.Safety 100%2.High oil yield 45%-55%
3.On-site guidence supported
4.The best scale and technology
5.Life more than 5 yrs
WASTE PLASTIC, RUBBER, TIRE TO VALUABLE CRUDE OIL
WORKING PRINCIPLE: CATALYTIC PYROLYSIS, COOLING, SEDIMENTATION AND SPLIT-FLOW.
Getting oil from waste plastic is through pyrolysis oiling technique, that is, to break the waste plastic by
heating or by adding some catalyst then to get polymerization monomer, diesel oil, gasoline, fuel oil,
mineral wax and so on. Pyrolysis oiling of waste plastic is not only pollution-free to environment, but also
can recycle energy effectively. In other words, the pyrolysis oiling is a kind of inverse process of
manufacturing plastic products with raw materials of petroleum in petrochemical industry. According to
the different composition of waste plastics, different catalyst is used for pyrolysis, compared with domestic
pyrolytic cracking oiling technology, ours increases the capacity efficiency, and improves the quality of oil.
The production line including following parts:
1. Constant temperature heating system
2. Continuous pyrolysis system
3. Carbon black production system
4. Flammable gas purification system
5. Flue gas purifying system
6. Control Panel
Unique characteristics of production line:
1. Adopts advanced low temperature pyrolysis patent technology, implement the continuous industrial
production, and fundamentally eliminate the environmental and safety concerns.
2. With patented heating technology, unique heat dispersion heating process, and low temperature sulfur
transfer agent to heat materials evenly, it not only makes high oil yield, but also ensures the good quality
of oil and carbon black.
3. Combustible gas from production can be reused in heating system after purification. And taking
advantage of waste heat recycling technology, so our machine can reach high thermal efficiency and reduce
the production cost greatly.
4. Low temperature pyrolysis technology greatly improves the safety performance and equipment service
life.
5. Special flue gas purification system can remove all pollutants in flue gas, H2S, CO, CO2, SO2, SO3,
NOX, NH3 and other organic compounds and solid particles, so that the emission index has meet the high
standards of Europe and America.
Models and Parameter:
| Model | DY-1 | DY-2 | DY-3 |
| Capacity per day | 6ton | 8ton | 10ton |
| Rotate furnace(MM) | 2200*4300 | 2200*4600 | 2200*5800 |
| structural style | Horizontal rotation | Horizontal rotation | Horizontal rotation |
| Pressure | ordinary pressure | ordinary pressure | ordinary pressure |
| Rotation speed | 1.2rmp | 0.4rmp | 0.4rmp |
| Rotary Motor | 4kw | 4kw | 4kw |
| type of cooling | water-cooling | water-cooling | water-cooling |
| Circulating water | 1.2t/h | 1.5t/h | 1.8 t/h |
| Noise dB(A) | ≤62 | ≤65 | ≤70 |
The main oil index from waste plastics.
Item |
Unit |
Fuel oil |
Density |
g/cm3 |
0.82-0.83 |
Freezing point |
oC |
10 |
Flashing point |
oC |
25 |
Kinetic viscosity |
mPa.s |
8 |
Fuel value |
kJ/kg |
9500 |
FInal output: Crude Oil
Pictures of main the whole production line
Reactor
The Innre durm of Reactor
Delivery pictures:
