Help Center4pin Female Mini Usb Connector, Micro Female 4 Pin Connector Socket
Related Products
-
5 Pin Mini Usb Connector Nickel-platedNegotiableMOQ: 2000 Pieces -
8 Pin Female Mini Usb Connector ,gold-platedUS$ 0.075 - 0.078MOQ: 2000 Pieces
-
5 Pin Female Mini Usb Connector Tin-platedNegotiableMOQ: 2000 Pieces
-
5 Pin Mini Female Usb Connector Tin-platedNegotiableMOQ: 2000 Pieces
-
Usb Power Socket Usb BF 90NegotiableMOQ: 2000 Pieces
4 pin usb connector:
Specification | ||||||||
Electrical Spec. | -Working Temperature :0°C ~+70°C Rated Load: DC 30V 0.5A Contact resistance: ≤30 ohm max Insulation resistance: ≥100MΩ Withstand voltage: AC 250V (50Hz)/min Insertion and extraction force: 5~30N Electrical Life: 5,000 cycles Min Mechanical Life: 10,000 cycles Min | |||||||
Material |
| |||||||
Application | Computer,MP3 player, MP4 player, digital video and camera, PDAs, GPS, flash drive and cable ASSY and PCB | |||||||
|
| |||||||
a) Visual inspection: socket surface is smooth,no damage,crack,pit,and corrosion on metal parts
b)
Features: |
1,A Type/B Type/Mini Type ect.kinds of connector design |
2,Flexibility design for terminal interface to ensure nice contact and prolong the operating force |
3,The place that the terminal contacting is gold-plated,it is to fast the data transmiting speed |
4,The place that terminal soldering is stannum-plated,it is to make the soldering better |
Services:
1.Size,color,materials and plating can be variable according to customer definition.
2..Consulting price on alitalk must reply ASAP in working days.
3.We can provide few as samples
