Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES)

Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) thumbnail-1
Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) thumbnail-2
Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) thumbnail-3
Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) photo-1
Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) photo-2
Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES) photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Solar On Grid and Off Grid Hybrid Inverter ,OEM,FADI
Model Number:
FD- 5048D-ES
Contact Supplier Request Quote Chat Now
Haining Fadi Solar Energy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai /Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Solar On Grid and Off Grid Hybrid Inverter ,OEM,FADI
Model Number FD- 5048D-ES
Specification Normal
Application Home
Output Voltage (V) AC 220V
Load Power (W) Depend
Solar Power (W) 5KW
Work Time (h) 24 Hours



Solar On Grid and Off  Grid Hybrid Inverter:

Model: FD- 5048D-ES





Solar On Grid and Off  Grid Hybrid Inverter function:

1.FD ES series bi-directional energy-storage inverter is applicable to both on-grid and off-grid PV systems.

2.It can control the flow of energy intelligently.

3.During the daytime, the PV plant generates electricity which can be provided to the loads.



Solar On Grid and Off  Grid Hybrid Inverter features:

1.Future conception for Solar

2.Charge controller and inverter integrated

3.Intelligent battery management function

4.Capable of being grid-interactive or grid-independent

5.Compatible with both Lead-acid and Li-Ion battery

6.More security & performance for same costs

7.IP65 dust-proof and water-proof rating
8.45°C full-load output

9.Monitoring inverters freely via computers or moblie phones
10.Fanless low-noise design



Solar inverter specification:

Nodel Name

FD-5048D-ES

FD-3648D-ES

Solar





Max. DC power(W)

5400

4200

Max. DC voltage (V)

580

MPPT voltage range (V)

125~550

Starting voltage (V)

125

Max. DC current (A)

15/15

No. of DC connectors

2

No. of MPPTs

2(can parallel)

DC connector

SUNCLIX / MC4/H4 (Optional)

Bttery

Battery Type

Lead-acid or Li-Ion

Lead-acid or Li-Ion

Norminal Voltage(V)

40-60

40-60

MAX Discharge power (W)

4600

2300

MAX Charge power (W)

2300, programmable

2300, programmable

Battery capacity (Ah)

>=100 (depending requirement)

>=100 (depending requirement)

Charging curve

3-stage adaptive with maintenance

3-stage adaptive with maintenance

Charge voltage (V)

57 (Optional)

57 (Optional)

Battery temperature compensation

included(Li-Ion)

included(Li-Ion)

Battery voltage sense

integrated

integrated

Current shunt

integrated

integrated

AC Output Data

Norminal AC power(W)

4600

3600

Max. AC power(W)

4600

3600

Peak power(Back-up)(W)

1.5x Pnom, 10sec

1.5x Pnom, 10sec

Max. AC current(A)

20

16

Norminal AC output

50/60Hz; 230Vac

AC output range

45~55Hz/55~65Hz; 180~270Vac

AC output (Back-up)

230Vac ±2%, 50Hz (60Hz Optional)±0.2%, THDv<3%(linear load)

THDi

<1.5%

Power factor

0.9 leading~0.9 lagging

Grid connection

Single phase

Efficiency

Max. efficiency

97.60%

97.60%

Euro efficiency

>97.0%

>97.0%

MPPT adaptation efficiency

>99.9%

Residual current monitoring unit

Integrated

Anti-islanding protection

Integrated

DC switch(PV)

Integrated

AC over current protection

Integrated

Insulation monitoring

Integrated

Certifications & Standards

Grid regulation

VDE4105, VDE 0126-1-1+A1, G83/2, G59/2, AS4777.2/.3, IEC62109-2

Safety

IEC62109-1&-2, AS3100, IEC62040-1

EMC

EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4, EN61000-3-11, EN61000-3-12

General Data

Dimensions (WxHxD)

516*440*184mm

Weight (kg)

30

28

Mounting

Wall bracket

Ambient temperature range

-25~60°C(>45°C derating)

Relative humidity

0~95%

Max. operating altitude

 2000m

Protection degree

IP65

Topology

Transformerless

Standby losses(W)

<8

Cooling

Nature convection

Noise emision(dB)

<25

Display

LED light & APP

Communication

USB2.0; WiFi

Standard warranty(years)

5/10/15/20/25(optional)



Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES)



Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES)



Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES)



Solar on-grid Inverter workshop:

Highy Quality 5KW Solar On Grid and Off Grid Hybrid Inverter (FD- 5048D-ES)
