Alarm Security System,mobile Phone Security Stand,iPad Display Secruity Systems

Shenzhen D.F.S Technology Co., Ltd.
Alarm Security System,mobile Phone Security Stand,iPad Display Secruity Systems thumbnail-1
Alarm Security System,mobile Phone Security Stand,iPad Display Secruity Systems photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Eastops
Model Number:
M017 with 2ports, Multi-2ports alarm host
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Eastops
Model Number M017 with 2ports, Multi-2ports alarm host

Specifications

Innovative solutions for valuable merchandise.
The perfect secure display solutions for mobile,tablet handheld electronic goods

 Tablet and mobile phone security stand

Display Charging Function apply to:Mobile Phone, Tablet and iPad.

8 ports display alarm holder that's good to protect the mobile phone,tablet pc and iPad for security experience displays for clients.



Basic Specification

Operating Voltage9~12VDC
Stand-by Current Consumption≤10.0mA
Activation Current Consumption≤250mA
Bi Tone Output≤120 db (Inner alarm), Optional: External Alarm or Speaker
Induction methodContact separation alarm, disconnection alarm, USB jack separation alarm
Multi TargetsMX-364 (4 targets), MX-366 (6 targets) , MX-368 (8 targets)
3 Different Display SelectableA.Metal Display Frame with USB Demo-Sensor B.Acrylic Display Frame with USB Demo-Sensor C.USB Demo-Sensor alone



Features:

  1. Consist of security controller and sensor.
  2. One alarm host can be connected with 2pcs, 4pcs, 8pcs,or 12pcs sensors.
  3. One remote controller maches 3 codes with one alarm host,more secure and perfect displays.
  4. Easy installation, portable and saving-cost.
  5. Charging +Alarm functions.
  6. Universal,affordable,widly used for mobile phones, ,laptops,cameras.

Caution:

  1. The host of the alarm should be placed in a more hidden and usually do not often encounter while on the other articles below, to avoid the alarm sound to be concealed.
  2. Open daily alarm and be sure to check the connection is connected, just open for the proposed increase in security should be reset once to do self-inspection, self-test and observe the corresponding port light is lit.



  Operating Step:

  1. Connect one end of the cable to the alarm (USB port), the other end connected to the object.
  2. The Adaptor jack plug into the alarm (on rear side).
  3. The power supply plug into AC outlet, the alarm horn chirping sound, the power is ON, the alarm panel turn ON indicator LED corresponding port, the host is already in the security state (in active position).
  4. Press red key on remote control to relief alarm, the alarm panel LED turns OFF.
  5. If the installation of equipment to port which way the light does not illuminate, indicating which way is not connected, reconnect until the LED lights ON.
  6. When the anti-theft device was break, or off line, the host immediately chirping alarm, while the corresponding port indicator light flashes, the staff on duty should be checked in the equipment of the ports and pay attention to whether there is "theft" by. Need to disarm the alarm status; you can press the Reset button (or remote button) to lift alarm.



Package Included:

  1. FC165A (Remote Control Smart Alarm).
  2. FC165u(USB mini cable, length ~6 feet).
  3. SM-0222 (Universal Adaptor 12Vdc 1,000mA).
  4. FC165 r (Remote Control) optional.
  5. FC165PMD(Smart Phone Metal Display) optional.
  6. FC165CMD (Camera Metal Display) optional.
  7. FC165TAD(Tablet Acrylic Display) optional.



 Alarm security system,mobile phone security stand,iPad display secruity systems

 iPhone5 and iPad mini sensor cable

 Alarm security system,mobile phone security stand,iPad display secruity systems



 Micro usb and Samsung mobile sensor cable

Alarm security system,mobile phone security stand,iPad display secruity systems



Micro usb and Samsung mobile sensor cable with LED

Alarm security system,mobile phone security stand,iPad display secruity systems



Samsung Tablet sensor cable

Alarm security system,mobile phone security stand,iPad display secruity systems



iPhone5 and iPad Mini sensor cable with LED

Alarm security system,mobile phone security stand,iPad display secruity systems



Micro usb and Samsung mobile sensor cable with LED

Alarm security system,mobile phone security stand,iPad display secruity systems



Remote Controller for Multi-ports







 Alarm security system,mobile phone security stand,iPad display secruity systemsAlarm security system,mobile phone security stand,iPad display secruity systemsAlarm security system,mobile phone security stand,iPad display secruity systems







 Alarm security system,mobile phone security stand,iPad display secruity systems
