Wind Solar Hybrid Charge Controller (300-1000W)

Name: Wind Solar Hybrid Charge Controller (300-1000W)
Brand: Leacy
SKU: 134482281

US$ 70 - 150 MOQ: 5 Packs

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Leacy

Model Number:

LWSR

Ningbo Haishu East Leacy Electrics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Leacy

Model Number LWSR

Application Charger Controller

Rated Voltage Other, 12V/24V

Maximum Current 50A

Wind solar hybrid charge controller (300-1000W)

Model	LWSR series
System voltage	12V	24V
Solar input	200W	150W	250W	300W
Wind input	300W	300W	500W	600W
Charge current	30A	20A	23A	37.5A
Charge protection	14.4V±1%	28.8V±1%
Floating Charge	13.8V±1%	27.6V±1%
Recover	13.2V±1%	26.4V±1%
Temperature Compensation	-24mV/℃	-48mV/℃
Over discharge off	10.8V±1%	21.8V±1%
Over discharge recover	12.3V±1%	24.6V±1%
Over voltage off	16V±1%	32V±1%
Over voltage recover	15V±1%	30V±1%
No-load Current	≤0.1A
Voltage drop (DC)	≤0.5V
Control mode	Fan MPPT charge function, PWM unload function, PWM flow current limiting function
Boost charge	Flexible independent boost circuit (optional)
Display	LCD(voltage/charge current/battery voltage)
Protection	Lightning protection, solar reverse charge protection, battery open-circuit protection, battery reverse protection, over wind speed and over-voltage soft automatic brake protection, overload protection etc
Working Temperature	-25℃~+55℃
Environment humidity	0~90%
Net Weight	1.20Kg
Dimension	*16214064mm*
