solar controller (10-20A with LCD)

Model

LPM-2410B/2420B/2410C/2420C

Rated Current

10A-30A

Rated Voltage

12V/24V

System Voltage

12V/24V

Output Overload/Short-circuit protection

1.25 times than rated current, protect the load within 60 seconds/ 1.5 times than rated current, protect the load within 5 seconds/ 2.0 times or over, starting the short circuit protection

No load loss

≤12 mA

Voltage drop of charging circuit

<0.2V

Voltage drop of discharging circuit

<0.1V

Working temperature

-25℃~+60℃

Elevated voltage

14.4V/28.8V

Float charging voltage

13.7V/27.4V

Temperature compensation

-4mv/cell/℃'

Low voltage disconnecting

11.2V/22.4V

Low voltage recovery

12.6V/25.2V

Charging mode

PWM
