Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > YSD PPF Pipe Press Former

YSD PPF Pipe Press Former

Name: YSD PPF Pipe Press Former
Brand: YSD,LVD-HD
SKU: 134475575
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

YSD,LVD-HD

Model Number:

PPF5200/125

Contact Supplier Request Quote Chat Now

(YSD) Hubei Tri-Ring Metalforming Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name YSD,LVD-HD

Model Number PPF5200/125

Machine Type Pipe and Tube Bending Machine

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Extra Services Machining

Certification CE

Specifications

CE&CSA certificate
"First Prize in China Machinery Industry Scientific and Technological Progress"
Obtain six national patent

PPF Series Multiple cylinders CNC synchronous bending forming machine was innovate and developed by YSD Company in lately years, it is the advanced technology and tremendous metal forming machine in the world. The machine are composed of main machine, front and back feeding system, front and back supporting system, roller conveyor, side discharge system, moulds tooling and CNC control system.

PPF series CNC pipe former adopt the technology of incremental forming technology, frame-type three-beam structure, multi-cylinder, electro-hydraulic servo synchronized CNC control, high accuracy comprehensation, automatic feeding, pipe forming, pipe rotation and automatic discharge and many other kinds of functions can be achieved on th maching.

It can produce the straight seam pipes with diameter of 406-1626mm and thickness of 60mm.

PPF 6500/135 CNC pipe former had awarded "First Prize in China Machinery Industry Scientific and Technological Progress" in 2008, and another six practical technologies on the machine had obtained the national patent.

Main Technical Specification:

Specification	Unit	3600/125	5200/125	6000/125	8000/125	10000/125
Pressing force	kN	36000	52000	60000	80000	100000
Full-face distance between housings	mm	12200	12500	12500	12500	12500
Bending length	mm	12000	12200	12200	12200	12200
Side distance between housings	mm	1500	1700	1700	1700	1700
Max. outer diameter of the bending pipe	mm	1400	1524	1524	1524	1524
Number of main cylinders		4	6	6	6	6
Max. open height	mm	2400	2500	2500	2500	2500
Stroke of the RAM	mm	400	400	400	400	400
Approaching speed	mm/s	60	60	60	60	60
Working speed	mm/s	7	9	8	8	6
Returning speed	mm/s	60	60	60	60	60
Main machine power	kw	315	615	615	750	750
Accessorial system power	kw	120	180	180	200	200
