Home > Products > Limit switch > IP66 High Temperature Stainless Steel Micro Switch
IP66 High Temperature Stainless Steel Micro Switch
- 100000 Piece / Pieces per Month
- Ningbo or Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Chre | Model Number: | NM7121 |
Protection Level: | IP65 | Operating Temperature: | 10~80 Degree | Max. Current: | 5A |
Max. Voltage: | 250VAC |
Product Description
CHRE 15A 250VAC Long Plunger Electrical Limit Switch
1.Product Description
1.Roller plunger limit switch
1)Strong metal outer shell.
2)Long life(20,000,000mechanical operations)
3)Stainless steel idler wheel,punch and spring.
4)Selective PG11 cable gland.
5)250V AC, 5A rated current ,50Hz ,
6)Completely Aluminium body ,Stainless steel roller plunger.
7) IP66
8)Selective PG11 cable gland. NO/NC
2. Specification
Double break Mechanism | INO+INC Force Break Snap action |
Rated voltage/current | 10(4)A,125,250VAC |
6(2)A,380VAC | |
For inductance load,Cos=0.4 | |
Contact resistance | Initial<10mΩ,after testing<30mΩ |
Instulation voltage | Min,100mΩ at 500VDC |
Delectric strength | AC2000 VAC1 minute for exposed metal/terminals,ground and between opposite ploes |
Electrical life | 500,000 at 10A 250VAC resistive at tripping PT 2.5mm-3.0mm |
Mechanical life | 20,000,000 at tripping PT 2.5mm-3.0mm |
Operating speed | 240 cycles/minute Max:1-160mm/second(mech) |
30 cycles/minute Max;1-20mm/second(rated elect) | |
Degree of protection | IP66 |
Ambient temperature rised | Max 30ºC over ambient temperature at rated voltage/current |
Operating temperature | -25ºC~+80ºC |
Storage temperature | -25ºC~+80ºC |
Humdity | 95'R.H.Max(No.dewing) |
Shock resistance | Free position 10G |
Overtravel position 30G | |
Vibration frequency | 55Hz Max |
Terminal screw locking force | 6-8gjf-cm |
Other forces | Cover 12-14kgf-cm/head 8-9kgf-cm/mounting 50-60kgf-cm |
Bare wire gauge | Φ2mm Max |
Cable diameter | Φ12mm Max |
3.Operating Characteristics
Specificaiton | Model | TSA-031 |
Operating force | OF Max | 400g-cm |
Release force | RF Min | 100g-cm |
Pre-travel | PT Max | 20º |
Tripping position | OT Min | 22.5º |
Movement Differential | MD Max | 10º |
Over Travel | OT Max | 75º |
Total travel | TT mm | 95º |
Rotary indexing | 22.5º | |
Weight | 650-715g |
FAQ
We are a manufacturer in the past to undertake design and processing of all types
2.Which payment can offer?
We accept 30% payment in advance, the balance payment before shipping.We also
3.Why choose us?
We are Alibaba Assessed 11 years Gold Supplier.We are a factory manufacturing
4. How can I get some samples?
