700ma constant current led driver power supply
Product parameters
Model |
Input voltage(AC) |
Working Frequency |
Output voltage |
Output Current |
Output power(DC) |
Working Temp. |
Protection grade |
SMT-070-0700CW |
100-265V |
47~63HZ |
50-70V |
700mA |
49W |
-25~50°C |
IP67 |
SMT-050-0900CW |
100-265V |
47~63HZ |
25-50V |
900mA |
45W |
-25~50°C |
IP67 |
| SMT-040-1050CW | 100-265V | 47~63HZ | 20-40V | 1050mA | 45W | -25~50°C | IP67 |
| SMT-040-1200CW | 100-265V | 47~63HZ | 30-40V | 1200mA | 48W | -25~50°C | IP67 |
| SMT-024-2000CW | 100-265V | 47~63HZ | 12-24V | 2000mA | 48W | -25~50°C | IP67 |
Specifications
- Model:SMT-070-0700CW
- input voltage:100-265vAC 47-63Hz
- output: 50-70v @700mA 49w
- product size: 122*58*26mm
- certificate:CE UL RoHS approval
- warranty: 2 years warranty
- Net weight: 650g
- Box size: 324*258*188mm
- Pack qty: 20pcs/ctn
- Gross Weight (Kg): 12kg/ctn
- waterproof rate: IP67
- outer case: Aluminum housing
- High efficiency,save energy ,protected environment
- High stability and low ripple, increase light efficiency and decrease light attenuation
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage
- Passed high ,low temperature and waterproof testing.
- Integrity protection,over loading, over voltage ,over current
- 8Hrs and 100% full load burn-in test.
- Working Temperature : -40 ~ +50°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
| 700ma constant current led driver power supply | |||
| Net weight (g) | Gross Weight/ctn | Qty/ctn | Carton size(mm) |
| 650 g | 12 kg | 20 pcs | 324*258*188mm |
