ip67 2000ma ce emc pass constant current led drivers
Product parameters
Model |
Input voltage(AC) |
Working Frequency |
Output voltage |
Output Current |
Output power(DC) |
Working Temp. |
Protection grade |
SMT-057-17500CW |
100-265V |
47~63HZ |
40-57V |
1750mA |
100W |
-25~50°C |
IP67 |
SMT-045-2000CW |
100-265V |
47~63HZ |
30-45V |
2000mA |
90W |
-25~50°C |
IP67 |
| SMT-042-2400CW | 100-265V | 47~63HZ | 20-42V | 2400mA | 100W | -25~50°C | IP67 |
| SMT-100 -1050CW | 100-265V | 47~63HZ | 80-100V | 1050mA | 105W | -25~50°C | IP67 |
| SMT-120-1050CW | 100-265V | 47~63HZ | 100-120V | 1050mA | 126W | -25~50°C | IP67 |
| SMT-084-1200CW | 100-265V | 47~63HZ | 65-84V | 1200mA | 100W | -25~50°C | IP67 |
| SMT-072-1400CW | 100-265V | 47~63HZ | 60-72V | 1400mA | 100W | -25~50°C | IP67 |
| SMT-050-2000CW | 100-265V | 47~63HZ | 30-50V | 2000mA | 100W | -25~50°C | IP67 |
| SMT-036-2800CW | 100-265V | 47~63HZ | 25-36V | 2800mA | 100W | -25~50°C | IP67 |
Specifications
- Model:SMT-045-2000CW
- input voltage:100-265vAC 47-63Hz
- output: 30-45v @2000mA 90w
- product size: 186*68*34mm
- certificate:CE UL RoHS approval
- warranty: 2 years warranty
- Net weight: 1210g
- Box size: 315*215*210mm
- Pack qty: 10pcs/ctn
- Gross Weight (Kg): 12kg/ctn
- waterproof rate: IP67
- outer case: Aluminum housing
- High efficiency,save energy ,protected environment
- High stability and low ripple, increase light efficiency and decrease light attenuation
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage
- Passed high ,low temperature and waterproof testing.
- Integrity protection,over loading, over voltage ,over current
- 8Hrs and 100% full load burn-in test.
- Working Temperature : -40 ~ +50°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
What kind of LED Driver/Power Supply We do??
We specialized in constant voltage & current LED drivers, 010v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.
|
Triac CC&CV Dimmable Series
|
0-10V CC&CV Dimmable Series
|
DALI CC&CV Dimmable Series
|
|
Wall-mount Power Adapter
|
HOME
|
Desktop Power Adapter
|
|
Constant Voltage Series
|
Enclosue Power Supply
|
Constant Current Series
|
What kind of power cords we can help you fix in our LED Driver/Power Supply??
Answer: We can help you fix / find all kinds of power cords to our drivers as per your request, for example:
Smarts Electronics, the led driver manufacturer located in Quanzhou,has 6 years trade experience in Alibaba.
We have 7 kinds of led drivers or led power supply:
1.Constant Voltage LED Driver;
2.Constant Current LED Driver;
3.Triac CC&CV Dimmable LED Driver
4.0-10v CC&CV Dimmable LED Driver
5.DALI CC&CV Dimmable LED Driver
6.Power Adapter
7.Switching Power Supply
All of our drivers are got UL/cUL CE ROHS listed .OEM Welcome.
Our led drivers are widely used for:
1.Indoor LED illuminating lights
2.LED Neon, LED urban Decoration
3.LED Lighting Advertising,LED Display
4.Safety Protection Apparatus
5.Telecommunications, Networks
6.Vehicle Lights, Controller Panels
our market:
Our major markets are in EU & North America,it takes about 85% markets share. view transaction history
factory & equipments view:
certifications:
CE, UL/CUL, ROHS approval.
What Service we can supply??
-
All inquiries will be replied within 24 hours
-
Professional manufacturer,welcom to visit our website
- OEM/ODM avaliable:
A.Print logo on our product;
B. Customized specification; - After Sales-Service:
A. All products will have 100% burn-in test and strictly quality test before shipping;
B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production; - High efficiency,long life span,reasonable&competetative price,fast lead time;
- We have our engineer team, if you have any question about your LED applications, let us know freely.
Frequently Asked Questions
Q1. What's the trade terms you can do??
A1: We accept EXW,FOB..(Optional)
Q2. What's shipping mode can we choose?
A2: Express, Ocean and air transportation (optional).
Q3. What's the MOQ?
A3: Our MOQ is 1pcs. better price for large quantity;
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during the warranty period.
Q5. Can i get products with my own logo??
A5: Sure, you can, MOQ is 500pcs.
Q6. Can i get a sample for testing??
A6: Sure, but sample fees should be charged on your account.
Q7. What's the mormal lead time??
A7: 7 working days for samples, 15 working days for mass production.
Q8. What's the payment conditon?
A8: T/T in advance or 30% deposit and 70% before delivery (optional)
Q9. What's the Payment do you have?
A9: We accept payment be sent via T/T, L/C, Trade Assurance, WESTERN UNION, PAYPAL.
