Help Center12v 24V 48W Led Driver
Related Products
Specifications
12v 24V 48W led driverLeading manufacturer
Input voltage: 100-240vAC
UL/CUL/CE approval
2 years warranty
12v 24V 48W led driver
Specifications
2) Leading manufacturer
3) Input voltage: 100-240vAC
4) UL/CUL/CE approval
SMTS-48W series (AC/DC single output desktop type switching power supply)
• 3 pole AC inlet IEC320-C14 • Fully enclosed plastic case
• Class I power (with earth pin) • Pass LPS for 16~48V
• Full output 5~48V safety approved • LED indicator for power on
• Protections: Short circuit / Overload / • Approvals: UL / CUL / CE
Over voltage • 2 year warranty
General Specification
Item No.: |
SMTS-48W series |
AC input voltage range ............. 100~240VAC / 1.9A
AC inrush current (max.) ........... Cold start, <40A at 230VAC
Overload protection................... Hiccup mode, auto-recovery
Over voltage protection .............110~140% rated output voltage
Hold up time...............................16ms at full load
Withstand voltage...................... I/P-O/P: 42VDC, 1minute
Working temperature..................0~40°C @ 100% load, 50°C @ 70% load
Safety standards........................ UL1950, TUV EN60950-1 approved
EMC standards.......................... EN55022-B, EN61000-3-2,3
Length of output cable................180cm of SPT-1,18AWG x2C
Standard DC plug....................... P2J: 2.1x5.5x10mm / C+, barrel type
|
SMTS-48W-001 SMTS-48W-002 SMTS-48W-003 |
7.5V / 0~2.93A |
±4% |
150mV |
78% |
9.0V / 0~2.77A |
±4% |
160mV |
78% |
|
12V / 0~2.08A |
±5% |
175mV |
79% |
|
15V / 0~1.66A |
±4% |
180mV |
79% |
|
18V / 0~1.38A |
±5% |
180mV |
78% |
|
24V / 0~1.04A |
±4% |
80mV |
77% |
|
30V / 0~1.5A |
±5% |
100mV |
78% |
|
48V / 0~0~1A |
±4% |
150mV |
78% |
desktop power supply
input voltage: 100-240vAC, 47~63Hz
output voltage: 12vDC , 24vDC, 36vDC, 48vDC
power: 60w, 72w, 90w
desktop power supply
input voltage: 100-240vAC, 47~63Hz
output voltage: 12vDC , 24vDC, 36vDC, 48vDC
power: 24w, 30w, 36w
(light up LED strips available)
desktop power supply
input voltage: 100-240vAC, 47~63Hz
output voltage: 12vDC , 18vDC, 24vDC, 36vDC, 48vDC
power: 90W, 100W, 120W
(LED strip lights available)
