Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > 277v Led Transformer

277v Led Transformer

Name: 277v Led Transformer
Brand: SMARTS
SKU: 134456147

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

SMARTS

Model Number:

SMT-012-060VW

Contact Supplier Request Quote Chat Now

Quanzhou Smarts Electronic & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name SMARTS

Model Number SMT-012-060VW

Output Power 51 - 100W

Output Type Single

Input Voltage Other, 100~305vAC

Output Voltage 12-50vDC

Output Frequency 50-60Hz

Output Current 1.25~5Amp

Specifications

277V Waterproof LED driver
1) LED driver with universal input
2) UL,CE, ROHS approval
3) Efficiency:>0.86
4) 2 years warraty

277vAC constant voltage LED power supply

Features:
• Size is 257*29*20mm
• Case material is Aluminum
• Wire requirement are Input white wire, Output wires: red "+" black"-"

General Specification:
• High efficiency,save energy ,protected environment
• High stability and low ripple, increase light efficiency and decrease light attention
• Meet to safety standard and EMC
• Assure LED stability long lift and light efficiency by constant current
• Passed high ,low temperature and waterproof testing.
• Integrity protection,over loading, over voltage ,over current
• 8Hrs and 100% full load burn-in test.

• CE,UL,ROHS approval

• 2 years warranty

Model	Input voltage (AC V)	Working Frequency (Hz)	Output voltage (DC V)	Output Current (DC m A)	Output power (DC W)	Working Temp.	Protection grade
SMT-012-060VW	100-305V	50/60	12V	5.0Amp	60W	-25~50°C	IP67
SMT-024-060VW	100-305V	50/60	24V	2.5Amp	60W	-25~50°C	IP67
SMT-036-060VW	100-305V	50/60	36V	1.67Amp	60W	-25~50°C	IP67
SMT-048-060VW	100-305V	50/60	48V	1.25Amp	60W	-25~50°C	IP67

Application:

Our products are widely used in various industries, such as outdoor LED illuminating lights, LED Neon, LED City Decoration, LED Lighting Advertising, LED Display, Safety Protection Apparatus, Telecommunications, Networks, Vehicle Lights, Controller Panels, etc.
