Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > 277v Led Transformer

277v Led Transformer

Name: 277v Led Transformer
Brand: SMARTS
SKU: 134456143

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

SMARTS

Model Number:

SMT-040-0500CW

Contact Supplier Request Quote Chat Now

Quanzhou Smarts Electronic & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name SMARTS

Model Number SMT-040-0500CW

Output Power 1 - 50W

Output Type Single

Input Voltage Other, 100-265V/170-305vAC

Output Voltage 10~800vDC

Output Frequency 50-60Hz

Output Current 300-900mA

Specifications

277V Waterproof LED driver
input:100-265v/ 170-305vac
UL,CE, ROHS approval
Full load 100% burn-in test
2 years warranty

(277vAC constant current waterproof LED power supply)

( 2 years warranty )

Features
• Size is 217*29*20mm
• Case material is Aluminum Housing
• Wire requirement are Input white wire, Output Red "+" Black"-"

General Specification
• High efficiency,save energy ,protected environment
• High stability and low ripple, increase light efficiency and decrease light attention
• Meet to safety standard and EMC
• Assure LED stability long lift and light efficiency by constant current
• Passed high ,low temperature and waterproof testing.
• Integrity protection,over loading, over voltage ,over current
• 8Hrs and 100% full load burn-in test.

Model	Input voltage(AC V)	Working Frequency (Hz)	Output voltage (DC V)	Output Current (DC mA)	Output power (DC W)	Working Temp.	Protection grade
SMT-060-0300CW	100-265V 170-305V	50/60Hz	50-60V	300mA	18W	-25~50°C	IP67
SMT-060-0320CW	100-265V 170-305V	50/60Hz	50-60V	320mA	19W	-25~50°C	IP67
SMT-050-0350CW	100-265V 170-305V	50/60Hz	40-50V	350mA	17.5W	-25~50°C	IP67
SMT-030-0500CW	100-265V 170-305V	50/60Hz	20-30V	500mA	15W	-25~50°C	IP67
SMT-040-0500CW	100-265V 170-305V	50/60Hz	30-40V	500mA	20W	-25~50°C	IP67
SMT-025-0700CW	100-265V 170-305V	50/60Hz	1.8-12V	700mA	17.5W	-25~50°C	IP67
SMT-030-0700CW	100-265V 170-305V	50/60Hz	20-30V	700mA	21W	-25~50°C	IP67
SMT-022-0750CW	100-265V 170-305V	50/60Hz	10-22V	750mA	16.5W	-25~50°C	IP67
SMT-020-0900CW	100-265V 170-305V	50/60Hz	10-20V	900mA	18W	-25~50°C	IP67

Application:

Our products are widely used in various industries, such as outdoor LED illuminating lights, LED Neon, LED City Decoration, LED Lighting Advertising, LED Display, Safety Protection Apparatus, Telecommunications, Networks, Vehicle Lights, Controller Panels, etc.
