7''(16:9) Tft Touch Screen Lcd Monitors

Model No.

                             AKA-070V3T

Panel type

                      7''(16:9) Digital panel

Touch screen

                                       Yes

Operating system

                       DOS/Window 9X ME,2K

                       XP Vista NT Windows

                       CE/LINUX/Mac

Touch screen interface

                      Serial (Rs232) or USB

Screen control

              OSD language menu : Chinese/English

AV Inputs

                 CVBS(RCA:Red/Yellow/White)x3

Recommended resolution

                        800x400@ 60Hz

 Viewing angle(U/D/L/R)

                            70/90/85/85

Active area(mm)

                             152.4x91.44

Display colors

                        16.7 million colors

 Pixel pitch

                                0.1905m

Contrast ratio

                        400:1 typical

Brightness

                       300cd/m² typical

Response time

                Rise+Fall (typicaly):12ms

PC input

15 pin D-Sub (analog RGB) for VGA input

Power supply

              85-265V AC Adaptor ,50~60Hz

Wall mount

                      VESA DDC 1/28

Unit N.W. / G.W.

                  Approx. 1.3KG/1.5KG

Gift box size

                 180x123x30(LxWxD mm)
