Specifications
Sreen size:26'' / 32'' /37"/42"Connectors: DC 12V/S-Video/VGA/BNC/RCA/Audio
Response time:8ms
This is an ideal choice for all Offices, CCTV Security, Education, Home and Government Users.
Features:
♦ Touch Screen: IR Single Touch, IR Dual Touch (Win.7)
♦ PIP/POP/PBP
♦ 3D Noice Reduction
♦ Full HD 1920x1080P
♦ Full series include 26"/32"/37"/42"
26'' /32'' HD LCD CCTV Monitors
Model No. |
AKA-2602MA |
AKA-3202MA |
Panel type |
26''(16:9) TFT Color LCD |
32''(16:9) TFT Color LCD |
| Solution No.(option) | M2(Ultra-Hi Definition) | M6(Ultra-Hi Definition) |
|
Video inputs Video outputs |
CVBS input(BNC)x2 CVBS Loop output(BNC)x1 S-video x1 HDMIx1 USBx1 Scartx1 |
CVBS input(BNC)x2 CVBS Loop output(BNC)x1 S-video x1 HDMIx1 |
|
Audio inputs Audio outputs |
RCA jack (L/R)x2 Stereo 3.5mm input x1 |
RCA jack (L/R)x2 Stereo 3.5mm input x1 Stereo 3.5mm onput x1 |
|
Built in comb filters Built in De-interlace |
3D 3D |
3D 3D |
Recommended resolution |
WXGA(1366x768) |
|
Power consumption |
approx. 37 watts |
approx. 46 watts |
Display colors |
16.7 million colors | |
Pixel pitch |
0.422mm | 0.511mm |
Contrast ratio |
1500:1 typical |
2000:1 typical |
Brightness |
500cd/m² typical | |
Response time |
8ms (GTG) | |
PC input |
15 pin D-Sub (analog RGB) for VGA input | |
Power supply |
AC 100V~240V | |
Screen control |
OSD multi-language menu | |
Radiation standard |
TCO 99 | |
Wall mount |
VESA | |
External Carton |
852x172x515 (LxWxD mm) |
863x260x673 (LxWxD mm) |
Full HD (1920x1080P) 37'' /42'' LCD CCTV Monitor
Model No. |
AKA-3702MA |
AKA-4202MA |
Panel type |
37''(16:9) TFT Color LCD |
42''(16:9) TFT Color LCD |
| Solution No.(option) | M2(Ultra-Hi Definition) | M6(Ultra-Hi Definition) |
|
Video inputs Video outputs |
CVBS input(BNC)x2 CVBS Loop output(BNC)x1 S-video x1 HDMIx1 USBx1 Scartx1 |
CVBS input(BNC)x2 CVBS Loop output(BNC)x1 S-video x1 HDMIx1 |
|
Audio inputs Audio outputs |
RCA jack (L/R)x2 Stereo 3.5mm input x1 |
RCA jack (L/R)x2 Stereo 3.5mm input x1 Stereo 3.5mm onput x1 |
|
Built in comb filters Built in De-interlace |
3D 3D |
3D 3D |
Recommended resolution |
Full HD (1920x1080) |
|
Power consumption |
approx. 53 watts |
approx. 58watts |
Display colors |
16.7 million colors | |
Pixel pitch |
0.2(H)x0.6(V) |
0.511mm |
Contrast ratio |
15000:1 typical |
|
Brightness |
450cd/m² typical |
500cd/m² typical |
Response time |
8ms (GTG) | |
PC input |
15 pin D-Sub (analog RGB) for VGA input | |
Power supply |
AC 100V~240V | |
Screen control |
OSD multi-language menu | |
Radiation standard |
TCO 99 | |
Wall mount |
VESA | |
External Carton |
1125x194x669 (LxWxD mm) |
1235x197x720 (LxWxD mm) |
