46 Inch 4x5 Narrow Bezel 6.7mm Professional DIY Video Wall
- F.O.B. Hong Kong
- T/T Credit Card
You May Like
-
46 Inch 1366x768 Resolution 450 Nits Home Video Wall
-
46 Inch In Stock Stature 1920x1080 LCD TV Wall
-
46 Inch 9.4mm Samsung Bezel 450 Nits Video Wall
-
46 Inch 9.4mm Samsung Bezel 450 Nits HDMI Video Wall
-
46 Inch In Stock Stature 1920x1080 DIY LCD TV Wall
-
46 Inch 3x3 Narrow Bezel Samsung Bezel New Original DID LCD TV Video Wall
Product Details
| Place of Origin | Guangdong, China | Brand Name | AZUQI | |
| Model Number | ATS-2046H | Type | TFT |
Product Description
Specifications
46 Inch DIY Video Wall1 . Resolution 1366x768
2 . Single display, full display, any combination
3. Narrow bezel 6.7mm
46 Inch 4x5 Narrow Bezel 6.7mm Professional DIY Video Wall
Application Field:
SOHO Offices
Shopping Mall
School
Government Users
Professional Solution Feature:
PIP/POP/Burn Free Display Function
1. MxN multi-units display
2. Single display (multi-channels signals)
3. Full screen display
4. Any combination display
HDMI Input
Video Input/Output: Display CVBS Signal by BNC Connector
Built in 3D Comb Filter
I. Specifications
| Model No. | AKA-2046 | |
| Display | Screen Size | 46 Inch Samsung DID Bezel |
| Lamp Type | 12pcs CCFL | |
| Max. Resolution | 1366 x 768 | |
| Pixel Pitch | 0.7455(H)x0.7455(V) mm | |
| Brightness | 450cd/m² | |
| Contrast Ratio | 3000:1 Typical | |
| Aspect Ratio | 16:9 | |
| Viewing Angle (L/R/U/D) | 89°/ 89°/ 89°/ 89° | |
| Display Color | 16.7 Million | |
| Response Time | 8 (Typ) (GTG) ms | |
| Super Narrow Bezel | 5.3mm Active to Active | |
| Double Bezel Seam | 6.7mm Active to Active | |
| Outline Dimension | 1025.653x579.884x59.53 mm (WxHxD) | |
| Video System | NTSC / PAL | |
| Controller Box Interface | Solution No. | M6 |
| HDMI Input | 1 | |
| DVI Input | 1 | |
| PC-RGB Input | VGA (15Pin D-Sub) x1 | |
| Video 1 Input | CVBS (BNC Type) x1 | |
| Video 2 Input | CVBS (BNC Type) x1 | |
| Video Output | CVBS (BNC Type) x1 | |
| YPbPr | (BNC Type) x3 | |
| RS232 Input | (LAN) x1 | |
| RS232 Output | (LAN) x2 | |
| USB Input | 1 | |
| IR-In | 1 | |
| Menu Key | 1 | |
| Power Supply Input | 1 (AC 110V-230V) | |
| LVDS Output | 1 | |
| Back Light | 1 | |
| Features | Built in Comb Filter | 3D |
| Built in De-interlace | 3D | |
| Burn Free/PIP/POP | Option | |
| Display Function | MxN multi-units/Single/Full Screen | |
| Source | VGA/HDMI/VIDEO 1/VIDEO 2/YPbPr/DVI | |
| Multi Language | English, Chinese, French, German, Italian, Portuguese, Spanish | |
| Cabinet | Color | Black |
| Material | Metal Casing | |
| Wall Mount | VESA | |
| Circumstance | Operating Temperature | 0°C ~ 50°C / 32°F ~ 122°F |
| Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F | |
| Packing | Unit N.W./G.W. | Approx. 23/24 KG |
| External Carton Size | 1155x370x685 mm (LxWxD ) (2pcs/CTN) | |
| *Specifications are subject to change without notice. | ||
II. Product Details:
A. Single unit image front view and back view
B. With the controller box, easy for installation and take off.
III. Installed on the Rack for Reference:
IV. Company Overview and Certifications for Reference
V. Our Service
1. Inquiries would be replied within 48 hours
2. OEM/ODM service is available:
Silk print OEM logo on the monitor; big quantities order would share customized gift box.
3. After-sale service:
All products have been strictly checked the quality and packed perfectly before shipping;
All products would share 1 year warranty after delivery according to our RMA policy;
4. Payment term:
T/T, PayPal, Western Union
5. Delivery
We have strong relationship with many express companies and logistic companies. And some of our forwarders as follows:

VI. More products for your choice
PS: Please send e-mail to us directly or chat online by trademanager for more details.
