55 Inch 3x3 Samsung DID Lcd Display RS232 Interface Video Wall

Model No.

AKA-2055

Display

Screen Size

55 Inch Samsung DID Bezel

Lamp Type

WLED

Max. Resolution

1920 x 1080

Pixel Pitch

0.630(H)x0.630(V) mm

Brightness

500cd/m²

Contrast Ratio

3000:1 Typical

Aspect Ratio

16:9

Viewing Angle (L/R/U/D)

89°/ 89°/ 89°/ 89°

Display Color

16.7 Million

Response Time

8 (Typ) (GTG) ms

Super Narrow Bezel

5.3mm Active to Active

Double Bezel Seam

6.3mm Active to Active

Outline Dimension

1215.5x686.3x80.6 mm (WxHxD)

Video System

NTSC / PAL

Controller Box Interface

Solution No.

M6

HDMI Input

1

DVI Input

1

PC-RGB Input

VGA  (15Pin D-Sub)  x1

Video 1 Input

CVBS (BNC Type)  x1

Video 2 Input

CVBS (BNC Type)  x1

Video Output

CVBS (BNC Type)  x1

YPbPr

(BNC Type)  x3

RS232 Input

(LAN) x1

RS232 Output

(LAN) x2

USB Input

1

IR-In

1

Menu Key

1

Power Supply Input

1 (AC 110V-230V)

LVDS Output

1

Back Light

1

Features

Built in Comb Filter

3D

Built in De-interlace

3D

Burn Free/PIP/POP

Option

Display Function

MxN multi-units/Single/Full Screen

Source

VGA/HDMI/VIDEO 1/VIDEO 2/YPbPr/DVI

Multi Language

English, Chinese, French, German, Italian, Portuguese, Spanish

Cabinet

Color

Black

Material

Metal Casing

Wall Mount

VESA

Circumstance

Operating Temperature

0°C ~ 50°C / 32°F ~ 122°F

Storage Temperature

-20°C ~ 60°C / -4°F ~ 140°F

Packing

Unit N.W./G.W.

Approx. 27/30KG

External Carton + External Wooden Case

*Specifications are subject to change without notice.
