46 Inch In Stock Stature 2x2 LCD TV Wall
- 500 Piece / Pieces per Month
- F.O.B. Hong Kong
- T/T Credit Card
You May Like
-
55 Inch Ultra Narrow Bezel XXX LED DIY Video Wall
-
55 Inch Narrow Benzel 5.3mm 4x5 Flexiable Video Wall Display
-
55 Inches RS232 Input Seamless LED Vidoe Wall
-
55 Inch Ultra Narrow 3.9mm Big Screen Video Wall
-
55 Inch 1920x1080 DID Bezel 3.9mm Ultra Slim Video Wall
-
46 inch narrow bezel 6.7mm professional DIY video wall
Product Details
Place of Origin | Guangdong, China | Brand Name | AZUQI | |
Model Number | ATS-2046H | Type | TFT |
Product Description
Specifications
2x2 LCD TV Wall1 . Resolution 1920x1080
2 . Single display, full display, any combination
3. Samsung DID Bezel: 9.4MM
46 Inch In Stock Stature 2x2 LCD TV Wall
Application Field:
SOHO Offices
Shopping Mall
School
Government Users
Professional Solution Feature:
PIP/POP/Burn Free Display Function
1. MxN multi-units display
2. Single display (multi-channels signals)
3. Full screen display
4. Any combination display
HDMI Input
Video Input/Output: Display CVBS Signal by BNC Connector
Built in 3D Comb Filter
I. Specifications
Model No. | AKA-2046 | |
Display | Screen Size | 46 Inch Samsung DID Bezel |
Lamp Type | 12pcs CCFL | |
Max. Resolution | 1920x 1080 | |
Pixel Pitch | 0.7455(H)x0.7455(V) mm | |
Brightness | 450cd/m² | |
Contrast Ratio | 3000:1 Typical | |
Aspect Ratio | 16:9 | |
Viewing Angle (L/R/U/D) | 89°/ 89°/ 89°/ 89° | |
Display Color | 16.7 Million | |
Response Time | 8 (Typ) (GTG) ms | |
Double Bezel Seam | Approx. 18mm Active to Active | |
Outline Dimension | 1025.653x579.884x59.53 mm (WxHxD) | |
Video System | NTSC / PAL | |
Controller Box Interface (Option) | Solution No. | M6 |
HDMI Input | 1 | |
DVI Input | 1 | |
PC-RGB Input | VGA (15Pin D-Sub) x1 | |
Video 1 Input | CVBS (BNC Type) x1 | |
Video 2 Input | CVBS (BNC Type) x1 | |
Video Output | CVBS (BNC Type) x1 | |
YPbPr | (BNC Type) x3 | |
RS232 Input | (LAN) x1 | |
RS232 Output | (LAN) x2 | |
USB Input | 1 | |
IR-In | 1 | |
Menu Key | 1 | |
Power Supply Input | 1 (AC 110V-230V) | |
LVDS Output | 1 | |
Back Light | 1 | |
Features | Built in Comb Filter | 3D |
Built in De-interlace | 3D | |
Burn Free/PIP/POP | Option | |
Display Function | MxN multi-units/Single/Full Screen | |
Source | VGA/HDMI/VIDEO 1/VIDEO 2/YPbPr/DVI | |
Multi Language | English, Chinese, French, German, Italian, Portuguese, Spanish | |
Cabinet | Color | Black |
Material | Metal Casing | |
Wall Mount | VESA | |
Circumstance | Operating Temperature | 0°C ~ 50°C / 32°F ~ 122°F |
Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F | |
Packing | Unit N.W./G.W. | Approx. 23/24 KG |
External Carton Size | 1155x370x685 mm (LxWxD ) (2pcs/CTN) | |
*Specifications are subject to change without notice. |
II. Product Details:
A. Single unit image front view and back view
B. With the controller box, easy for installation and take off.
III. Super Narrow Bezel Installed on the Rack
IV. Company Overview and Certifications for Reference
V. Our Service
1. Inquiries would be replied within 48 hours
2. OEM/ODM service is available:
Silk print OEM logo on the monitor; big quantities order would share customized gift box.
3. After-sale service:
All products have been strictly checked the quality and packed perfectly before shipping;
All products would share 1 year warranty after delivery according to our RMA policy;
4. Payment term:
T/T, PayPal, Western Union
5. Delivery
We have strong relationship with many express companies and logistic companies. And some of our forwarders as follows:
VI. More products for you
For more details? Contact me, Please.
