Product Details

Place of Origin	Sichuan, China		Brand Name	SHIDA
Model Number	SDC-3000G

supports ASI input receiving data of DVB ASI transport stream from encoder, multiplexer, DVB gateway, scrambler

Product Descriptiooution

Outlline

IP-ASI Adapter/Gateway is one of the main equipments for digital TV head-end. It supports ASI input receiving

data of DVB ASI transport stream from encoder, multiplexer, DVB gateway, scrambler, video server and other

DVB head-ends, and outputs IP/UDP streams (TS over IP); and it can also support IP transport stream from

network input and ASI TS stream output.

Features

1 Full duplex

2 8MB cache, anti-burst stream

3 Real-time stream monitoring

4 LCD/Keyboard control by front panel and network management by Ethernet

Specifications

Input	ASI	BNC interface
Output	Gigabit IP Port	UDP/RTP, MPTS/Multicast, TS over IP
Control		network RJ-45, 10/100M, base-TX, NMS
Control		Keyboard + LCD
General Features	Size	482mm×280mm×44mm
	Temperature Range	0~45°C (Operation); -20~80°C (Storage)
	Power	100-240VAC, 50Hz, 25W
