Specifications
used for DVB ASI and Ethernet tmaximum receive 12 channel IP and output 12 ASI
transmit the 12 IP stream into 12 TS stream
Features
1 Supports IP to ASI one-way conversion
2 Supports double GE ports, and inputs 1Gps data
3 Supports UDP, unicast and multicast mode, and 1GMP V2/V3
4 Supports 12 ASI output channel, and each channel has two ASI ( the same data) interfaces
5The maximum conversion channel of IP to ASI is 12, and the maximum bit-rate in each channel is 96Mbps,
the maximum total bit-rate is 840Mbps
6 Supports to eliminate the IP transport shake, and can correctly restore the PCR of TS stream 7
7 Keyboard and NMS operation
Specifications
Interface |
Input |
Two 1000M network serial input interfaces,RJ45 interface |
Output |
12 ASI output, and each channel has two BNC interfaces |
|
Transfer Protocol |
Input |
TS over UDP,unicast and multicast |
Output |
DVB-ASI |
|
Bit-rate |
Max of each channel is 96Mbps Max total bit-rate is 840Mbps |
|
General |
Dimension(WxLxH) |
482mm×410mm×44mm |
Weight |
4kg |
|
Temperature |
0~45°C(working ),-20~80°C(storage) |
|
Power supply |
100~240VAC,50/60Hz |
|
Power consumption |
22W |
|
