Help CenterT210 Pressure Transmitter/Sensor
Related Products
-
T2000 Water Pump Pressure SensorUS$ 15 - 160MOQ: 10 Pieces -
T2000 Pressure TransmitterUS$ 15 - 160MOQ: 10 Pieces
-
HG40 Pressure Sensor/TransducerNegotiableMOQ: 10 Pieces
-
T3000 Liquid Level Transmitter / Sensor / TransducerUS$ 80 - 160MOQ: 1 Piece
-
Refrigeration Pressure SensorUS$ 15 - 160MOQ: 10 Pieces
The heart of T2000 is a ceramic pressure sensor that is temperature compensated and laser trimmed for accurate span and offset calibration. The typical advantage is the compact size, which make it convenient to be installed in small room. Some typical applications for these pressure sensor are: Process control and automation, compressors and pumps, engine controls, off road vehicles to name few.
Measuring Range |
0~4…60bar (nomal range) |
-1~4…100bar , 0~2…3bar , 0~61bar…600bar | |
Output / Power Supply |
4~20mA / 12~30VDC (2 wire) |
0.5~4.5V / 5VDC (3 wire ) | |
0/1~5V / 10~30VDC/AC (3 wire ) | |
0~10V / 12~30VDC/AC (3 wire ) | |
Accuracy: ±0.5%F.S,±1.0%F.S | |
Stable: ±0.5%F.S, ±1.0%F.S (Max) | |
Overload Capability: 1.5 times full scale | |
Burst Pressure: 3 times full scale | |
Response time : 10ms | |
Medium Temperature Range : -40 °C~+100 °C | |
Temperature Influence Automatically Amending Range : -10°C~+80°C | |
Storage Temperature Range: -50 °C~+125°C | |
Sample line connection: male G1/4, NPT1/4, M20×1.5, G1/2, 7/16-20UNF(other connection is available on request) | |
Electrical Connection: Packard, DIN 43650C , M12 Series, Cable | |
Protection Class: IP67 | |
Pressure Form: Guage pressure | |
Insulation Resistance: >100M Ω@50V | |
Electro Magnetic Compatibility: EN50081-1/-2; EN50082-2 | |
Material |
Enclosure: 1Cr18Ni9Ti Stainless Steel |
Connection: 1Cr18Ni9Ti Stainless Steel | |
Wet material: Ceramic | |
