Y98-200 Hydraulic Bottle Blowing Machinery
- 50 Set / Sets per Month
- China Port
- T/T
-
4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
-
automatic welding machine for stainless steel commerical sink panel and bowl
-
Stainless Steel Heavy and large Box Semi-Automatic Polishing Machine Gantry Polishing Machine
-
SPECIAL METAL WIRE WEAVING MACHINE
-
MODERN WIRE MESH WEAVING MACHINES FROM LANYING FOR BRASS WIRE MESH WEAVING
-
LANYING stainless steel woven wire mesh machines
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | yongheng | Model Number: | Y98-200 |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Y98-200 Hydraulic Bottle Blowing Machinery
1.Suitable for:
Y98-200 Hydraulic Bottle Blowing Machinery is used for forming the part with complex surface.Can be used for the hydraulic bulging process of vacuum cup,thermos bottle,water bottle and other tableware and containers made of stainless steel,copper,aluminum,iron and other materials.
2.Main Feature:
1.Application:for forming the part with complex surface.
2.Speed control of the second section of moving beam;No-load rapid & slow copy deep drawing
3.Safety protection device should be equipped to provide security guarantee for the operators
4.Auto count function should be equipped
5.Locking-mould force and water pressure are adjustable
3.Main technical specification:
DESCRIPTION | UNIT | Y98-200 |
Nominal Capacity | KN | 1000 |
Master Cylinder Stroke | MM | 750 |
Nominal Capacity Of Pressurized Cylinder | KN | 1000 |
Stroke Of Pressurized Cylinder | MM | 350 |
Max. Capacity Of Injection Cylinder | L | 7 |
Max. Injection Pressure Of Injection Cylinder | MPA | 50 |
Max. Shut Height | MM | 1300 |
Working Table Size | MM | 650(L) x 650(W) |
Sliding Platform Size | MM | 550(L) x 450(W) |
Downing Speed | MM/S | 360 |
Pressing Speed | MM/S | 30 |
Return Speed | MM/S | 300 |
Motor Power | KW | 15+2.2 |
Overall Size | MM | 2200(L) x 1600(W) x 3750(H) |
