Specifications
A4 Automatic Copy Paper Cutting Machine1.4-5T/8hour
2.Automatic A4 Paper Cutting
3.PLC,Servo Motor
4.weight:70-85g/m2
Detail of A4 Automatic Copy Paper Cutting Machine:
A4/A3 Automatic Copy Paper Cutting Machine Use and characteristics:
This machine is suitable for all kinds of paper, paper plastic compound class, color printing compound packing material type and other large roll cut-off cut. 1. This machine adopts PLC touch screen control, servo motor, control, fixed-length cut. 2. Transmission using pneumatic, photoelectric sensors, centralized control, the machine set of light, electricity, gas one, simple, shear and high precision, mechanical stability, low noise. 3. Motor speed regulation, automatic counting, alarm stop, and magnetic tension control. Can longitudinal sections of cutting, waste side with fan automatically excluded.
Automatic Copy Paper Cutting Machine Main technical parameters:
Model |
1100 |
1300 |
Effective width |
1100mm |
1300mm |
Maximum diameter of raw materials |
Φ1400mm |
Φ1400mm |
Minimum width of vertical cut |
50mm |
50mm |
Cutting Length |
20-400mm |
20-400mm |
Cutting speed |
10-140m/min |
10-140m/min |
Cutting precision |
±0.2mm |
±0.2mm |
Total power |
19kw |
20kw |
Weight |
7000kg |
7500kg |
Dimensions(L×W×H) |
17500x1950x2000mm |
17500x2250x2000mm |
A4 Automatic Copy Paper Cutting Machine key configuration:
1) 4 have ground lift shaft of paper planes, the maximum diameter of 1350mm
2) sets of tension control system
3) with anti-warp drive in aluminum roller
4) six components of tangential knives and one set of cross-cutting knife
5) low High-speed paper feeding system
6) Automatic waste discharge device
7)folder automatic sorting machinery, transport equipment
8) equipped with automatic stop device off paper
9) PLC to make paper counting device
10) PLC process control system and touch screen click data parameter system
11) four photoelectric eye correction system
12)Four rolls of vertical and horizontal cut at the same time.
Skype: ritayuan99
Finished A3 A4 Sheet Paper Usage:
Automatic A3/A4 Paper Cutting Machine The Automatic Arranging :
Automatic Copy Paper Cutting Machine Feeding Unit: 4 Rolls Paper As Raw Material , with air cylinder
A4 Automatic Paper Cutting Machine Magnetic Tension Control:
Copy Paper Cutting Machine Electric Error Controller :
A4 Automatic Copy Paper Cutting Machine Round Knife and Flat Knife For Cross Cutting And Length Cutting: with Servo motor control
Automatic Paper Cutting Machine Computer Control Plate: With PLC
Automatic Paper Cutting Machine Complete Line : Two Models In Factory
Four Paper Rolls Material Feeding : 4-5T/8hours
Two Roll Paper Material Feeding Model: 2-3T/8 hours
Our Services:
we will send technician to install and training your work after the machine arrived your factory,another questions about machine can talk with me online,we will solved it within 2days.
Packaging & Shipping :
In normal we use the stretch film for simple package . If the customer required we also can use the wooden box pacakge .
Package details:
