Specifications
Paper Cutting & Package Machine1.Automatic type ,4-5T/8hour
2.Roll paper cutting
3.PLC,Servo control
4.In stock
Detail of Paper Cutting & Package Machine
A4 Paper Cutting Machine Use and characteristics:
This machine is mainly used in the production of A3, A4 copy paper cutting.Servo motor to control the cutting length, with high precision, mechanical stability, less waste and so on
This machine is suitable for all kinds of paper, paper plastic compound class, color printing compound packing material type and other large roll cut-off cut. 1. This machine adopts PLC touch screen control, servo motor, control, fixed-length cut. 2. Transmission using pneumatic, photoelectric sensors, centralized control, the machine set of light, electricity, gas one, simple, shear and high precision, mechanical stability, low noise. 3. Motor speed regulation, automatic counting, alarm stop, and magnetic tension control. Can longitudinal sections of cutting, waste side with fan automatically excluded.
Paper Cutting & Package Machine Price Products Details:
Model |
DK-1100 |
DK-1300 |
Effective width |
1100mm |
1300mm |
Maximum diameter of raw materials |
Φ1400mm |
Φ1400mm |
Minimum width of vertical cut |
50mm |
50mm |
Cutting Length |
20-400mm |
20-400mm |
Cutting speed |
10-140m/min |
10-140m/min |
Cutting precision |
±0.2mm |
±0.2mm |
Total power |
19kw |
20kw |
Weight |
7000kg |
7500kg |
Dimensions(L×W×H) |
17500x1950x2000mm |
17500x2250x2000mm |
Skype: ritayuan99
Welcome To Contact Me
Finished A3 A4 Paper Usage:
Automatic A4 paper Stacker:
The Paper Cutting & Package Machine Feeding Unit: Roll Paper As Raw Material , with air cylinder
The Paper Cutting Machine Magnetic powder: Tension Control
A4 Roll Paper Cutting & Package Machine Electric Error Controller :
The Paper Cutting Machine Circular Knife and Flat Knife For Cross Cutting And Length Cutting: with Srvo motor control
Paper Cutting & Package Machine --Computer Control Plate: With PLC
A4 Paper Cutting Machine Traction Unit :
Paper Cutting & Package Machine Complete Line :
Four Rolls Paper Material Feeding : 4-5T/8hours
Two Rolls Paper Feeding Model: 2-3T/8 hours
Our Factory Machine Certificate:
Company Photos:
