DK-M15 Model 15.6 Inch PLC Touch Screen Program Control Guillotine Paper Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Paper Cutting Machine
Computerized:
Other, Yes, Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Price High Quality Computer Control Automatic A4 Copy Paper Packaging MachineUS$ 43,500 - 46,500MOQ: 1 Set -
Low Price High Quality Computer Control Automatic A4 Paper Packaging MachineUS$ 43,500 - 46,500MOQ: 1 Set
-
Hot Sale High Output Computer Control Automatic A4 Paper Packaging Machine/ Copy Paper Packaging MachineUS$ 43,500 - 46,500MOQ: 1 Set
-
High Quality Hot Sale Computer Control Automatic Copy Paper Wrapping MachineUS$ 43,500 - 46,500MOQ: 1 Set
-
Hot Sale High Quality Automatic Computer Control Paper Roll Wrapping Machine/ Paper Wrapping MachineUS$ 43,500 - 46,500MOQ: 1 Set
Condition
New
Type
Paper Cutting Machine
Computerized
Other, Yes, Yes
Place of Origin
Zhejiang, China
Brand Name
Duke
Model Number
M15
Voltage
380V/220V
Power(W)
3kw
Dimension(L*W*H)
228*140*188 cm
Weight
2500kg
Certification
CE ,AAA , ISO 9001
Warranty
One Year
After-sales Service Provided
Engineers available to service machinery overseas
DK-M15 Model 15.6 Inch PLC Touch Screen Program Control Guillotine Paper Cutting Machine
Industrail Guillotine Paper Cutting Machine Computer System
1. The up-to-date 15.6" Widescreen LCD, full touch screen; Siemens PLC control.
Eight languages to choose. 2. Metric system and British system two units, show the dimensions of the front knife and the back knife. 3. Position resolution of backgauge is 0.01mm, closed-loop control, the locating error is less 0.01mm; No need to adjust locating error. Max. Backgauge speed is 15m/min.
4. The program storage capacity is 300 programs. Every program can store 299 items cutting sizes. The storage memory has a maximum of 40 years. 5. With USB, transmit data, to convenient operator make programming and arrangement via PC. 6. Equipped with fault deagnostics and non-repreat safety guards. 7. The backgauge is driven by a Panasonic servo-motor with four speed levels. 8. With automatic pushing paper function, the distance can be adjusted. 9. Adjustable time delay for knife activation, accurate and convenient. 10. Uses icons to show operational functions, which are simple and user friendly.
11. Clamp pressure adjustment by the computer system(optional). 12. With full automatic cutting function.
13. The backgauge and knife movements can be monitored on the screen.
Guillotine Paper Cutting Machine Performance
1. Knife-seat guiding structure with sliding block type, cam type for adjusting-knife mechanism.
2. Clamp press paper stack through hydraulic system, the spring re-position.
3. Worm gear drive mechanism, hydraulic clutch, mechanical brake.
4. Hydraulic system adopts Germany advanced technology, the hydraulic units are ISO approved, Italy oil pump.
5. One-piece, slotless and chrome-plated cast iron work table is sturdy and easy to maintain.
6. Import ball screw with double linear guides to drive backgauge.
7. High safety infrared protection device according to CE standard.
8. Main electronic units are from French TE and Japanese ORMON famous international brands.
1. The up-to-date 15.6" Widescreen LCD, full touch screen; Siemens PLC control.
Eight languages to choose. 2. Metric system and British system two units, show the dimensions of the front knife and the back knife. 3. Position resolution of backgauge is 0.01mm, closed-loop control, the locating error is less 0.01mm; No need to adjust locating error. Max. Backgauge speed is 15m/min.
4. The program storage capacity is 300 programs. Every program can store 299 items cutting sizes. The storage memory has a maximum of 40 years. 5. With USB, transmit data, to convenient operator make programming and arrangement via PC. 6. Equipped with fault deagnostics and non-repreat safety guards. 7. The backgauge is driven by a Panasonic servo-motor with four speed levels. 8. With automatic pushing paper function, the distance can be adjusted. 9. Adjustable time delay for knife activation, accurate and convenient. 10. Uses icons to show operational functions, which are simple and user friendly.
11. Clamp pressure adjustment by the computer system(optional). 12. With full automatic cutting function.
13. The backgauge and knife movements can be monitored on the screen.
Guillotine Paper Cutting Machine Performance
1. Knife-seat guiding structure with sliding block type, cam type for adjusting-knife mechanism.
2. Clamp press paper stack through hydraulic system, the spring re-position.
3. Worm gear drive mechanism, hydraulic clutch, mechanical brake.
4. Hydraulic system adopts Germany advanced technology, the hydraulic units are ISO approved, Italy oil pump.
5. One-piece, slotless and chrome-plated cast iron work table is sturdy and easy to maintain.
6. Import ball screw with double linear guides to drive backgauge.
7. High safety infrared protection device according to CE standard.
8. Main electronic units are from French TE and Japanese ORMON famous international brands.
| Model | 168G | ||
| Max. Cutting Width | cm | 168 | |
| inch | 66.1 | ||
| Max. Cutting Length | cm | 168 | |
| inch | 66.1 | ||
| Max. Cutting Height | cm | 16.5 | |
| inch | 6.5 | ||
|
Min. Cutting Size |
without false clamp plate | cm | 3 |
| inch | 1.2 | ||
| with false clamp plate | cm | 9 | |
| inch | 3.5 | ||
| Front Table Length | cm | 75 | |
| inch | 29.5 | ||
| Max. Clamp Pressure | N | 60000 | |
| Cutting Speed | time/min | 45 | |
| Main Motor | KW | 5.5 | |
This Guillotine Paper Cutting Machine Widely Used:
Hydraulic Paper Cutting Machine Real Pictures :
This Paper Cutting Machine Fix With 15.6’’Color touch Interface From Taiwan Brand
Other Auxiliary Machinery
Stack Lift
Stack Loader
Complete Line
Factory WorkShop
Machine Packaging And Shipping : Wooden Case Is More Safe
Every month have machine in stock , welcome visit anytime .
