Ruian Factory Direct Paper Cutter Machine For Proformations
1.Auto counting and auto warning
2.100 times/min
3.PLC,Touch Screen
4.In stock
We are Paper Cutting Machine Manufacturers,this Paper Transverse Cutting Machine is suitable for cutting the large coil packaging material,such as the paper, papaer plastic complex material and color printing complex material,etc This machine is widely used for application in the industries of paper processing and printing packaging.
Ruian Factory Direct Paper Cutter Machine For Proformations Function:
1,This Paper Transverse Cutting Machine adopts the servo motor (or stepless motor) to control the fixed-length cutting .It is equipped with the photoelectric tracing modifying system.
2,This machine integrates photo. electricity liquid and as a whole, PLC touching screen (manual or antomatic), and has the features operation,high-precision cutting,state operation and low noise.
3, The machine has the fenture of the motor frequency speed adjustment.
4.automation counting, giving an alarm when stop. and tension with digital indication.
Paper Cutting Machine Main technical parameters:
|
Model parameters |
DKHHJX-1100 |
DKHHJX-1300 |
DKHHJX-1600 |
||
|
maximum diameter of raw materials |
1400mm |
1400mm |
1400mm |
||
|
The largest-cut width |
1100mm |
1300mm |
1600mm |
||
|
The accuracy |
20-1200mm |
20-1200mm |
20-1200mm |
||
|
Precision of fixed |
±0.2mm |
±0.2mm |
±0.2mm |
||
|
Productivity |
100 m/min |
100 m/min |
100 m/min |
||
|
Total power |
11kw |
13kw |
15kw |
||
|
Weight |
2300kg |
2600kg |
3000kg |
||
|
Applicable power |
380v/50Hz(three phases four wire) |
||||
|
Dimensions (mm) |
5500×1850×1200 |
5500×2100×1250 |
6000×2400×1250 |
||
Machine Photos :
All of our machine use wooden case pacakge for shipping .
Professional team: more than 10 years engineer , engineer available for oversea installation .
Now factory have some machine in stock , welcome visit us anytime
if you have any question ,pls feel free to contact me !
I am waiting for at any time
We focus on : high quality machine (50 years working without problems)
Low price --------italy quality level, china commodity price
After sale service-------24 hours answer to clear your confusion
We have ready machine in workshop, welcome visiting !
