GBDR-600 Two Layers Automatic Servo Motor Continue Rolling Garbage Bag Making Machine/ Garbage Bag Making Machine

This Rolling Bag Making Machine is specially-designed point-cut rolling dual-purpose one for T-shirt & Flat-opening bag, is controlled by a computer. The step (servo) setting length system reduces the sealing-cutting dimensions errors, and the installation of photoelectric eyes track help make the position of figure of printing bags accurate. The computer numerical control can be selected to adjust the length of bag. The machine will automatically stop and sound a warning if there is something wrong with the printing the high and low density polyethylene film bags produced by the machine are applied to shopping in the super markets, shops and markets.



Model	GBDR -500	GBDR -600	GBDR -700	GBDR -800
Max bag-making width(mm)	400	500	600	700
Max bag-making length(mm)	1200	1200	1200	1200
Thickness of bag-making(mm)	0.008-0.10	0.008-0.10	0.008-0.10	0.008-0.10
Speed of bag-making(pc/min)	40-120	40-120	40-120	40-120
Power of motor	1.1kw	1.1kw	1.5kw	1.5
Electric Heating power	1.2kw	1.6kw	2kw	2.2
Mechanical Dimension	3300*1100*1500	3300*1200*1500	3300*1300*1500	3300*1400*1500
Weight of machine	800kg	850kg	900kg	1000
Packing dimension	3400*1200*1700	3400*1300*1700	3400*1400*1700	3400*1500*1700
Packing weight	1000kg	1060kg	1180kg	1220
