Specifications
1.Hot Cutting Plastic Bag Making Machine2.120X2 pcs/minute
3.Plastic T-shirt Bag Maker
4.Two lines
5.Have Stock
Hot Cutting Plastic Bag Making Machine Feature:
This machine is applied to manufacturing and printing the uncolored vest bags made of HDPE, LDPE roll film. It adopts PLC control, double servo (step) motor fixed length and the liquid crystal touch screen actual display to finish the feeding, sealing, cutting, punching holes and transporting only in one process. It is of high degree of automation and good economic result.
Main Technical Variables:
Model |
DFHQ-350x2 |
DFHQ-450x2 |
Max. Bag-making width |
300mm*2 |
400mm*2 |
Max. Bag-making length |
650mm |
650mm |
Bag-making thickness |
0.015-0.035mm |
0.015-0.035mm |
Bag-making speed |
140-200pcs/minx2 |
140-200pcs/minx2 |
Air pressure |
5kg/cm2 |
5kg/cm2 |
Total Power |
7kw |
9kw |
Weight of machine |
1.4T |
1.6T |
Overall dimensions |
6000*1400*1600mm(LxWxH) |
6000*1600*1800mm(LxWxH) |
Bag Samples:
