Three Side Sealing Bag Making Machine (DK-CC)
Performance and characteristics
FSD600SZL is designed and manufactured upon exporting. There are such features as photoelectric control, automatic material feeding device, photoelectric color code tracker.
(1)Servo motor which controls speed and length of the bag.
(2)With accurate photoelectric color code tracker, the machine can automatically stop in case of wrong color marks.
Machine show :
Our products including :
1. Blown film machines: double layer and 3 layers co-extrusion film blowing machine,
double die head film blowing machine, 3 layers co-extrusion film blowing machine, rotary die dead blown film machine, PVC film making machine, ziplock bag film blowing machine;
2. Bag making machines: bottom sealing bag making machine, side sealing bag making machine, courier bag making machine, double lane bag making machine, ziplock bag making machine, bags en roll making machine, etc;
3. Printing machines: rotogravure printing machine, flexographic printing machine, 1-8 colors for your choice.
4. Other machines: film folding machine, crushing & granulating machine, patch handle sealing machine, glue spraying machine, etc.
5. Machinery accessories: material mixing machine, guesset bag making machine, holes punching die, corona treater etc.
The main packaging products we produce:
1. PE bag, PP bag, OPP bag, PP bag;
2. Carrier bags,T-shirt bag, handle bag, shopping bag, bottom-sealing bag;
3. Courier bag, zip lock bag, self-adhesive bag, side-sealing bag.
4. Styles available: stand up, gusset, zipped, heat-sealed, heat-cut, cold-cut, blown, sealed-in the-middle,three-side-sealed, with handle or hanger hole
It is best machine for producing food, pesticide packaging.
| 1. | Bag forming type | Three side sealing, standing, zippered bag |
| 2. | Motor control | Industrial computer (HANGZHOU) |
| 3. | Structure of master drive | Coaxial eccentric |
| 4. | Power of main electric motor | 3.5kw, 1set (MITSUBISHI, JAPAN) |
| 5. | VGM reducer | Speed rate (10:1) completed with main motor (TAIWAN) |
| 6. | Main loading motor power | 370kw |
| 7. | Power of standing bag releasing motor | 180kw 2sets |
| 8. | Traction servo | 1.0kw 1set (PANASONIC, JAPAN) |
| 9. | Feeding servo | 1.5kw 1set; 1.0kw 1set (PANASONIC, JAPAN) |
| 10. | Tension control | MITSUBISHI magnetic powder brake and rotary encoder |
| 11. | Main release machine | Pneumatic releasing axle |
| 12. | Error correcting for releasing | Dual photoelectric, three-phase bridge rectification (JAPAN) |
| 13. | Pneumatic component | Made in TAIWAN |
| 14. | Punching beam | 3sets (former 2 + later 1) |
| 15. | Punching machine | 4sets (former 2 + later 2) |
| 16. | Photoelectric bag forming | 3 |
| 17. | Temperature control | 22lines |
| 18. | Cross heat sealing | 5groups (effective length 640mm) |
| 19. | Longitudinal heat sealing | 4groups (effective length 640mm) |
| 20. | Zipper heat sealing | 2groups (effective length 640mm) |
| 21. | Cross cooling | 2groups (effective length 640mm) |
| 22. | Longitudinal cooling | 4groups (effective length 510mm) |
| 23. | Zipper cooling | 2groups (effective length 330mm) |
| 24. | Max. main releasing width | 1200mm |
| 25. | Max. main releasing diameter | 800mm |
| 26. | Max. width of standing bag padding | 180mm |
| 27. | Max. diameter of standing bag padding | 400mm |
| 28. | Bag forming capacity | 35m/min. |
| 29. | Bag forming speed | Three side sealing bag making machine |
| 30. | Multi-speed function | 6 |
| Bag Shape | standing bag | |
| W: the width of the bag | 75-300mm | |
| L: the length of the bag | 75-540mm | |
| G: the height of a erected bag | 20-50mm | |
| A: the width of side seal | 10mm | |
| B: the width of end seal | ||
| ZP: the position of zipper | 35mm | |
FAQ:
1.Q:Are you a factory or trade company?
R:We are a factory & Trade company.
2.Q:Where is your company located?How can I visit there?
R:Our company is located in Ruian City,Wenzhou area,Zhejiang province,China.
About 1 hour by plane from Shanghai to Wenzhou,then 1 hour taxi to our place(5 hours by fast
train to Ruian station)
3.Q:what is the raw material does the machine ?
R:the material is A4 Paper Sheet
4.Q:who can answer my urgent questions about the machine?
R:leave a message when I am not online,will reply you within 24hours.
5.Q:how does your factory do regarding quality control?
R:our company policy is “quality first,customer first”.we have a QC manager whom check
the machine making from beginning to the end.
if you have any question ,pls feel free to contact me !
I am waiting for at any time
We focus on : high quality machine (50 years working without problems)
Low price --------italy quality level, china commodity price
After sale service-------24 hours answer to clear your confusion
We have ready machine in workshop, welcome visiting !
Compare, and then, purchase!
