HOT 4 Inch Digital LCD Panel With LED Backlight

Name: HOT 4 Inch Digital LCD Panel With LED Backlight
Brand: Silicon
SKU: 134340987

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Silicon

Model Number:

Silicon P-005

Shenzhen Silicon Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Silicon

Model Number Silicon P-005

Type TFT

Specifications

1. HOT 4 Inch Digital LCD Panel with LED Backlight
2. Use for display equipment
3. Input signal: CVBS
4. Datasheet: yes

1. Application:

Building interphone, car reversing system

Industrial controlling system, medical equipment

Audiovisual equipment Car display, Portable DVD Player

Household Video door bell, Videophone, Digital Camera

2. Feature:

Product Name	HOT 4 Inch Digital LCD Panel with LED Backlight
Product Number	P-005
Backlight	LED
Resolution	*320RGB234*
View Angle ( up/down/left/right )	60/70/75/75
Brightness	> 220Cd/m²
Input Signal	CVBS
System Format	PAL/NTSC (Auto switch)
Supply Voltage	10-18V
Rated Power	2.5W
Adjust Model	Menu adjust
PCB Structural Dimension(mm)	*80(w)60(h)7.2(d)*
Screen Size(mm)	*96(w)76(h)5.7(d)*
Operating Temperature	-20~70°C
Relative Humidity	5~95% RH
Storage Temperature	-30~80°C
Packing	60pcs/Box
Customize	Free for LOGO, accept order the CABLE lines
