Home > Products > Non-Optical BGA Rework Station > Shuttle Star SP360C BGA repair Motherboard /computer /phone machine
Shuttle Star SP360C BGA repair Motherboard /computer /phone machine
- 400 Set / Sets per Month
- Shenzhen/Hongkong
- Credit Card PayPal
- Denoh For Connecting Automation Special Machine 500e Dgn Flux Core Welding Machine Multi Function
- High Quality Multi-function Integrated Multi-purpose Multifunctional Welding Machine
- 500e Dgn Flux Core Integrated Multi-purpose Multi-function Welder
- Denoh Digital Push Wire Type Engine Welding Machine
- Denoh Engine Welding Machine Push Wire Type High Quality China
- Denoh Multi-function Welder For Connecting Automation Special Machine At Wholesale Price
Product Details
Place of Origin: | Guangdong, China | Brand Name: | shuttle star | Model Number: | SP360C |
Voltage: | 220V | Dimensions: | 650*500*600mm | Weight: | Approx. 36KGS |
Usage: | bga rework | Certification: | ISO 9001:2000 CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SP360C motherboard repair equipment
Specification:
Max PCB size: | 430mmX350mm |
Min PCB size: | 20mmX20mm |
Max BGA size: | 55mmX55mm |
Min BGA size: | 7mmX7mm |
Max BGA weight: | 80g |
Power for operation: | 3600W |
Upper hot air heater | 800W |
Lower hot air heater | 800W |
Bottom IR heater: | 2000W |
Machine dimension: | 650*500*600mm |
Machine weight: | 36KG |
Power supply: | AC singal-phase220V 3.6KW |
***************************************************************************************************************
Description
* High quality heating material produces high-tem breeze, precisely controlling the soldering and desoldering process.
* Movable heating head, able to move horizontally; easy to operate;
* Embedded industrial computer, touch screen interface, PLC control; real-time temperature curve display, able to display set curve and practically-tested curve; 7.2 high definition screen, convenient for operation and observation;
* Industrial computer able to store unlimited temperature curves, curve analysis can be done on touch screen; both English and Chinese can be input;
* The temperatures of the upper and lower heater can be precisely controlled according to set temperatures; bottom constant temperature infrared heating area; appropriate temperature control apparatus can ensure safe rework for BGA;
* The BGA soldering supporting frame can micro-adjusted to avoid local sinkage;
* Powerful cross flow can cool the lower heating area;
* The adjustable PCB positioning supports, easy and fast to install PCB; special fixture for installing allotype boards ;
* with sound alarming function after finishing soldering or desoldering; hand vacuum pen easy for picking up BGA;
* Set with over temperature alarming and protection function;
* Equipped with different hot gas nozzles, easy to replace; can be customized according to specific needs;
* The integrated design of machine and chassis is room-saving.
****************************************************************************************************************************************************
Equipped with different hot gas nozzles, easy to replace; can be customized according to specific needs
* Warranty:
1 Year Manufacturers warranty except for wear items like nozzles, tips and elements. Service is done in China .
Call us if you have any questions : +8618274966607
* Payments:
TT/ PayPal / Western Union is our preferred method of payment. After your payment, we will deliver machines within 7 working days.
Packed in wooden cases.
Transportation way can choose, express, shipping, air freight, freight charges shall be borne by buyer.
*********************************************************************************************************************************************************
