1. Wood grinder HX1250-400 Characteristics:
1) Advanced structure
2) High chipping quality
3) Hydraulic control, easy operation, easy maintenance
2. Wood grinder HX1250-400 Application:
1). Wood material with diameter ≤350mm
3. Wood grinder HX1250-400 Technical parameters:
Type |
HX1250-500 |
Blade rotational speed ( rpm) |
650 |
Hammer number (piece) |
22 |
Input size (mm) |
1250 – 400 |
Rotational speed (rpm) |
590 |
Rate of feeding (meter per minute) |
33 |
Max raw material diameter (mm) |
350 |
Output Chips size (mm) |
30-50 |
Main power (kw) |
132 |
Feeding conveyer length (m) |
6 |
Output conveyer length (m) |
10 |
Size (mm) |
7120 x 2820 x 2580 |
Capacity (ton per hour) |
15-20 |
Weight (t) |
7 |
Delivery |
1 x 40’FR |
4. Wood grinder HX1250-400 Featured Photo
5. Wood grinder HX1250-400 Main Structure
1) Hammer rotor
2) Link-joint feeding conveyor
6. Wood grinder HX1250-400 Test of Rotor
All rotor will go through strict Dynamic balance test and Static balance test to guarantee running stability after finish manufacturing and assembling.
7. Manufacturing photo
8. Wood grinder HX1250-400 Output Production
9. Wood grinder HX1250-400 Packing & Delivery
10. CE Certificate
11. Warranty
1) All quote include all accessories.
2) One year guarantee time from the date of acceptance of the machine (except wearing parts). During the warranty period, Seller will supply replacement parts or repair them for free, which are proved to be defective on materials or quality when users properly operate under normal working conditions.
3) Provide clients with reliable and timely After-Sales Service and Technology Support.
12. Company Introduction
1).15 years of experience in biomass energy crushing industry, located in Zouping County, Shandong Province, China.
2).Main products: Log debarker, Wood chipper, Sawdust machine, Drum dryer, Vertical ring die pellet machine (biomass pellet machine), Counter flow cooling separator, Packing machine; Comprehensive crusher, Building templates crusher, Plancon crusher (Stump grinder), Brush chipper, Diesel engine mobile wood chipper, Complete pellet production line.
3).Manufacture independently the key machines of pellet production line, can design complete production line according to customers’ needs.
4).Covers an area of 40,000 square meters, with more than 200 people including 120 specialized technicians and 8 senior engineers.
5).More than 100 sets of machineries of assembling, processing and transportation, etc.
6).Formed a complete systematic management system, can offer non-standard products according to customers’ request.
7).ISO9001certified. CE certified.
8).Provide clients with reliable and timely After-Sales Service and Technology Support.
13. Factory Corner
