Product name: Mini Extender
Product category: Digital HD video fiber optic transmission system
Product introduction
1. Overview
HC3611K transmits 1-channel 4K DVI video signal over one fiber, single mode or multimode, without compression, scaling and adjustments. It is ideal for Digital signage, broadcast or corporate studio, auditorium, stadium and theater, airport or transportation hub, distance learning, and surgical or medical imaging applications, to name a few.
2. Features
(1) 1-ch 4K resolution DVI
(2) 10-bit digital video encoding and uncompressed transmission technology
(3) Applied to the needs of computer long-distance transmission of industrial monitoring, large venues etc…
(4) Strictly selection material and quality control in order to ensure high quality and high reliability
(5) DVI, HDMl interface optional
(6) System status could be monitored by the power and other parameters LED indicator
(7) Compact size
(8) Excellent cost performance
(9) SMT Surface Mount Technology
(10) Lower power consumption and free installation, jitter
3. Specifications
a) Video
Channel: 1
Video type: RGB with stand-alone and sync H, V
Input level: 1Vp-p
Output level: 1Vp-p
Bandwidth: (-3 dB):10G
Digital bits wide: 10bits
Connector: HD-15 (DVI,HDMI optional)
b) Optics
Wavelength: 1310/1550nm
Fiber optic type: single-mode
Max. Link loss: 12dB (bigger options)
Output power: –5 ~ –10dBm
Receiver sensitivity: 18dBm
Connector: FC/PC (SC or ST optional)
c) Power and environmental indication
Stand-alone power: 5W
Insertion power: 5W
Power adapter: 220VAC to 12VDC/1A
Operating temperature: -40°C to +70°C
Relative humidity: < 95% (no condensation)
d) Dimension
Mini type
4. Applications
Remote OB Van/Truck Video Feeds;
Broadcast Studio Camera Feeds;
Long-haul Signal Transport;
TV station/video conference;
Lecture Hall Projector Connectivity;
Medical/Surgical Room Broadcast;
Small corporate campus video links
5. Ordering information
DVI Digital fiber optic transmission
HC3611K-T/R
4K resolution DVI, single fiber, singel mode for 300m or 2KM, multimode for 300M optional.Mini type
