Product Details
Place of Origin: | Beijing, China | Brand Name: | Hcstcom | Model Number: | HC3620KVM |
Product Description
DVI fiber optic extender with KVM function
« 1-channel DVI video signal of computer and 1-channel bidirectional stereo audio and 1-ch duplex data RS232 over one fiber optic
« Optional USB for K&B, 16-ch DVI over single fiber cable
« HDTV highest resolution 1200 x 1920@60Hz, 1080P and compatible with lower
« 10-bit digital video encoding and uncompressed transmission technology with 5.4G bandwidth
« Applied to the needs of computer long-distance transmission of industrial monitoring, large venues etc…
« Strictly selection material and quality control in order to ensure high quality and high reliability
« System status could be monitored by the power and other parameters LED indicator
« Excellent cost performance
« Support 1U and 4U rack mount
« Lower power consumption and free installation, debugging
Parameter | Description | |
Video | Standards | DVI 1.0; HDCP 1.2 |
Maximum pixel clock | 165MHz | |
Maximum data rate | 6.75Gbps | |
Resolution | 1920*1080@60Hz 1920*1080@50Hz 1920*1080@30Hz 1920*1080@25Hz 1920*1080@24Hz 1080I@60Hz 1080I@50Hz 1280*720@60Hz 1280*720@50Hz | |
Connector | DVI-D | |
Impedance | 100Ω | |
Audio | Interface | 3.5mm earphone seat |
Signal type | Stereo | |
K/M | Interface | To PC: MINI-USB To keyboard and mouse: USB-A |
RS232 | Interface | Industrial terminal |
Signal direction | Unidirectional | |
Baud rate | Self-adaptive, Max:115200bps | |
Data bits | 8 | |
Optical fiber | Interface | LC connector |
Fiber type | Single-mode single fiber | |
Wavelength | Single-mode 1310nm | |
Interface bandwidth | 2.97Gbps | |
Transmission distance | standard 20km | |
Other | Power supply | The power adapter: DC 5V/2A |
Power dissipation | MAX 6W | |
Temperature | Operating: -5℃ ~ +70℃ | |
Humidity | Operating: 5% ~ 90% | |
Dimension | 136*130*30mm | |
The warranty | 1 year free warranty, life-long maintenance |
« Video wall
« video conference, live teaching,
« Long-haul Signal Transport
« High-way, Metro, PIS system
« Lecture Hall Projector Connectivity
« Medical/Surgical Room Broadcast
« Building to Building video conference calling
« Small corporate campus video links
