Ultra-thin Body Fashion and Convenient Monitor

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Used

Application:

Desktop

Screen Size:

Other, 24"

Shenzhen KTC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen port

Delivery Detail:

Delivery time depends on order quantity.

Products Status Used

Application Desktop

Screen Size Other, 24"

Response Time Other, 14ms

Brightness 250cd/m

Interface Type D-Sub, HDMI

Contrast Ratio 1000:1

Resolution 1920 x 1080

Widescreen Yes

Panel Type IPS

Pixel Pitch 0.2745

Brand Name OEM

Model Number W2402S

Place of Origin Guangdong, China

Panel specifications
Size	23.8" diagonal
Panel	FHD IPS
Display scale	16:9
Backlight	ELED edge Type
Maximum resolution	1920×1080
Best working resolution	1920×1080@60Hz
Pixel Pitch	0.2745 (H) x 0.2745 (V)
Active Area	527.04mm×296.46mm
Viewing angle	H:178º,V:178º(CR>10)
Center Luminance of White	Min:200cd/m2;Typ:250cd/m2
Contrast ratio	Typ:1000:1
Response time	Typ:14ms
Display Colors	16.7 M
Color Gamut(NTSC)	Typ:65%
Interface configuration
Solutions		TSUMU58VHN	TSUMP38CDMT9
Input Interface	DVI-D	1	-
	HDMI	-	1
	VGA	1	1
Structure size
Base	model(optional)	BCE1-24
	Rotate	Nonsupport
	Elevation adjustment	Support
Size: w×h×t	product size(without base)	550324.531.6mm(Thinnest:8.5mm)
	product size(with base)	55040031.6mm
	Packing size	620470100mm
Weight	With BCE1-24:Net weight 2.8Kg,Gross weight:3.75Kg
Wall hanging size	Nonsupport
Power management
Power(DC Power Adapter)	DC 12V/3A
Working consumption	≤30W
Standby consumption	≤0.5W
Audio power(Optional)	2*2W
Special Functions
Non Flash Screen	Support(DC Adjust)
Blue-light filtering	Support
Safety&Certification
Safety	Withstand voltage strength	3000V 5s
	Leakage current	<3.5mA
	Earthing protective resistance	<100mΩ
Authentication	CCC,CE(Refer to the actual requirements of the customer)
Environment	Working condition	Temperature:5℃~40℃ humidity:10%~85% atmosphere:86KPa~104KPa
	Storage condition	Temperature:-20℃~55℃ humidity:5%~95% atmosphere:86kPa~104kPa
Accessory
LED Monitor	1PCS
Base	1PCS(Optional)
Instructions	1PCS
Data Line	1PCS (VGA Cable)
Power cord	1PCS
