2016 Best Selling Large Screen Monitor

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Used

Application:

Desktop

Screen Size:

Other, 32"

Shenzhen KTC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Products Status Used

Application Desktop

Screen Size Other, 32"

Response Time 8ms

Brightness 300cd/m

Interface Type DVI, HDMI, Other, DVI, HDMI, DP

Contrast Ratio 1000:1

Resolution Other, 4K*2K

Widescreen Yes

Panel Type IPS

Pixel Pitch Standard

Brand Name OEM

Model Number U3201S

Place of Origin Guangdong, China

Panel specifications
Size	31.5" diagonal
Panel	UHD VA
Display scale	16:9
Backlight	ELED edge Type
Maximum resolution	3840×2160
Best working resolution	3840×2160@60Hz
Pixel Pitch	0.181mm×0.181mm
Active Area	698.4mm×392.85mm
Viewing angle	H:178º,V:178º(CR>10)
Center Luminance of White	Min.:250cd/m2;Typ:300cd/m2
Contrast ratio	Typ.:1000:1
Response time	Typ:9.5ms
Display Colors	1.073 G
Color Gamut(NTSC)	Typ.:80%










Interface configuration
Mainboard model	SM2796A
Input Interface	DVI-D	1
	HDMI	2(HDMI2.0+HDMI1.4)
	DP	1(DP1.2)
	PC-Audio	1
Output Interface	Earphone	1
Structure size
Base	model(optional)	BCEA-32
	Rotate	Nonsupport
	Elevation adjustment	Support
Size: w×h×t	product size(without base)	725×426×49mm(The thinnest:14mm)
	product size(with base)	with BCEA-32:725×499×49mm
	Packing size	with BCEA-32:895×525×125mm
Weight	with BCEA-32:net weight 6Kg,gross weight:7.5Kg
Wall hanging size	100mm×100mm
Power management
Power input	100V-240VAC 60/50Hz
Working consumption	≤60W
Standby consumption	≤0.5W
Audio power	2*2W
Special Functions
Blue-light filtering	Support
Safety&Certification
Safety	Withstand voltage strength	3000V 1min
	Leakage current	≤0.35mA(230V input)
	Earthing protective resistance	TBD
Authentication	CCC,CE(Refer to the actual requirements of the customer)
Environment	Working condition	Temperature:5℃~40℃ humidity:10%~85% atmosphere:86KPa~104KPa
	Storage condition	Temperature:-20℃~55℃ humidity:5%~95% atmosphere:86kPa~104kPa
Accessory
LED Monitor	1PCS
Base	1PCS(Optional)
Instructions	1PCS
Data Line	1PCS (HDMI Cable )
Power cord	1PCS
