300 * 500mm MDF Mini Laser Engraving Machine
Mini Laser Engraving Machine
With up and down worktable, Simple frame and elegant appearance,
it is easy to operate and can process many kinds of arts and crafts with different sizes.
Applicable Material
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
1. Adopts RECI laser tube: glass tube 80W/100W
2. CE/FDA certificate
3. Full sealed laser optic system, high efficient beam transfer, easy maintenance
4. Equipped with the imported mirror and lens, ensure the best cutting effect
5. Strong and stable mechanical structure which makes moving speed, stability, precision greatly enhanced, the max speed can reach 15m/min
6. It adopts the International standard linear guide rail, which makes machine running more smoothly and accurately.
7. Multi-protection function ensures the movement security and personnel safety.
8. Adopts Stepper motor System: little inertia & good dynamic performance.
9. Industrial water cooling system ensures good performance and stability.
10. Windows interface that supports DXF, PLT, AI, BMP file formats
Type |
WER-3050SC |
Engraving Area |
300 * 500mm |
Laser Power |
40W/ 60W |
Driving Method |
Step Motor |
Cutting depth |
Acrylic 10mm |
Engraving speed |
0-400mm/s |
Cutting speed |
0-400mm/s |
Minimum Shaping Character |
English 1.5*1.5mm, Chinese 2.5*2.5mm |
Resetting positioning accuracy |
Max 0.1mm |
Power supply |
AC220V(110V)±10% 50HZ |
Working Temperature |
0-45°C |
Circulating water temperature |
5-25°C |
Water cooling |
Yes |
Data form Supported |
CDR, AI, BMP, PLT, DXF, DST, DWG, DSB |
Communication Interface |
USB2.0 |
Recommended Spare Parts |
Laser Tube |
Machine size |
1160*700*460mm |
Packing dimensions |
1280*830*600mm |
Gross Weight |
80kgs |
dot pointer for laser head: For marking the laser shooting position at laser head during the laser engraving or cutting
2) Industrial water chiller: Better working performance than water pump
3) Air filter cleaner: With air filter to clean the dusts, ashes and smells produced from laser engraving or cutting
4) Rotary attachment: For working with round or cylinder materials as Wine Bottles, Beer Cups, Etc
