BIOBASE1000 Elisa analyzer, Elisa reader&washer with CE,ISO certificate

                       BIOBASE1000  Elisa analyzer, Elisa reader&washer with CE,ISO certificate

BIOBASE1000Automated ELISA Processor

BIOBASE1000 Elisa Processors is fully automated two-plate ELISA processing system capable of adding sample,incubation,washing and data processing.

It is complete solution for your IVD ELISA assays. The system combines a high precision pipetting unit with stable incubators and efficiency washers and photometer unit.

BIOBASE1000 Modularity

1 Robotic hand.

1 Pipetting probe, 1ul stepping (1000ul volumes).

80 Sample rack, 92 Dilution rack.

2 units 96 well microplate(pipetting,incubator,reading).

1 unit independent washer&reader( two 8 nozzle manifolds).

Testing Range:

1. TORCH SERIES              4. THYROID AUTOIMMUNITY SERIES

Toxo, RV, CMV, HSV etc.         T3, T4, FT3, TSH etc

2. HEPATITIS SERIES           5. ENDOCRINE SERIES

HAV, HBV, HCV, HDV, HEV etc.   E2, E3, LH, FSH, HCG, Pro, PRL etc.

3. VENEREAL SERIES          6. TUMOR MARKER SERIES

HIV, TP, MP, CT etc.             CEA, AFP, PSA F-PSA, CAL9-9, CAL 25, CA15-3, CA242.

Modularity Composition:

2 microplate ,80 Sample rack, 92 Dilution rack.

All-in-one microplate reader and washer

8 special reagent racks, 1 general reagent racks.

Robotic precision probes and automated washing system.

Washer:

Two 8 nozzle manifolds

Automatic liquid level sensor detection

Separate aspiration and dispense probes prevent cross contamination

Reader:

8 independent photometric channels

Wavelength range 400-700nm

2 precision filters (450,630nm), 2 more available on request.

User-friendly Software:

LIS system available (laboratory information system)

Large data storage capacity

Professional service software monitor process on line status.

Technical Parameters:
