Help CenterCeiling Purlin Roll Forming Machine/steel Strip Stud Profile c z Purlin Cold Roll Forming Machine
Related Products
-
Customized Steel Frame C Z Shape Purline Roll Forming MachineryUS$ 7,000 - 10,000MOQ: 1 Set -
c z Purlin Roll Forming Machine Metal Processing Equipment Used Metal Roof Panel Roll Forming MachineUS$ 7,000 - 10,000MOQ: 1 Set
-
Automatic Steel Colored 80-100 c Purlin Roll Forming MachineUS$ 7,000 - 10,000MOQ: 1 Set
-
Aluminum Suspended Slatting Ceiling Roll Forming Machine Strip Ceiling Roll Forming MachineUS$ 12,000 - 12,500MOQ: 1 Set
-
C,Z,U Purlin Roof Metal Sheet Roll Forming MachineUS$ 6,500 - 12,000MOQ: 1 Set
1.Thickness:1.5-3mm
2.Voltage:220-440V
3.Auto production line
4.PLC control system
c z purlin cold roll forming machine
Configurations |
Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Body Of Roll Forming Machine, Hydraulic-Motor, Hole-Punch Device ,Cutting Device ,Hydraulic Station ,PLC Control. |
Control System |
PLC Delta Inverter |
Main Frame |
400mm H-Beam |
Main Power |
18.5 kw |
Pump Power |
15kw |
Power Supply |
3-Phase,380V,50Hz |
Forming Speed |
8-12m/min |
Hydraulic Pressure |
18-20MPa |
Forming Size |
60-300mm |
Feeding Thickness |
1.2-3mm |
Roller Station |
12 Stands |
Roller Diameter |
80mm |
Backboard Thickness |
20mm |
Chain Size |
66mm |
Cutter Standard |
Cr12 |
Roller Standard |
Cr12 |
Cr-Plating Size |
0.05mm |
Overall Size |
10500mm×1500mm×140mm |
Profile Drawing:
1.Installation and Training of Machine Manufacturer:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the roll forming machine for sale , and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service of Roll Forming Machine for Sale:
a.One year guarantee for whole roll forming machine for sale.
b.24 hours technical support by email or calling
c.If there is any problem found of steel roof sheet roll forming machinery, we will repair roll forming machine for sale for free in one year.
We are a Chinese company which specially produce roll forming machine.It' named Boutou jinbaili roll forming machinery Co.,Ltd ,which is one of the earliest companies dealing with exporting roll forming machines.Owning advanced equipment and excellent designer our products has reached leading level by high efficiency, high precision and low waste.
We have high technological background,advanced and mature production equipment and perfect means of inspection.We not only produce different type of professional roll forming machine,but also developed intelligent automatic production line of roll forming equipment,C shape purline machine and precipitator anodde plate forming machine ect. We have developed automatic production line of roll forming machine,roof panel,wall panel forming machine series,Glazed tile roll forming machine series,Floor deck forming machine series,Highway barrier forming machine series,double deck color steel tile roll forming machine series,C,Z shaped steel purline machine series,ach camber machine series and bending machine series,insulated sandwich panel machine on the base of traditional roll forming machine ,fair frame and standard model.
We are wholeheartedly committed to quality and customer service, primarily since we want to be ranked as the "best" in our business. Quality is not just another goal; it is our basic strategy for survival and future growth.
1. Are you manufacturer?
Yes, we are manufacturer and trading company.
2. What information you need before quote me?
We need profile drawin gof the panel you want to produce, material information and your special requirements
3. What payment terms you accept?
Commonly is TT, 30% deposit and 70% before shipment, and sometimes we can consider more for you as per your request.
4. Can you make machine according to my design?
Yes, we have experienced technical team to work out the suitable design for you and confirm with you until you agree.
5. What is the warranty for our machine?
We have one year guarantee, and provide whole life's technical support
6. Is there any spare part send for free?
Yes, pls contact us we can talk it
7.Is the machine automatic?
Yes, it can be manual and automatic
