Home > Products > Rubber Mixing > Rubber mixing banbury machine
Rubber mixing banbury machine
- 200 Set / Sets per Month
- Qingdao Seaport
- T/T Credit Card
Product Details
Condition: | New | Type: | Rubber Mixer | Place of Origin: | Shandong, China |
Brand Name: | PLASTSEA | Model Number: | 370L | Voltage: | 380V/50HZ |
Certification: | CE | Warranty: | ONE YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Rubber mixing banbury machine1.Drop-type discharge
2.Pneumatic and Hydraulic ram
3.Intermeshing rotor & tangential rotor
Rubber Mixing Machine.
This mixer is mainly used for tyre industry.
We can supply the mixer as below:
GK series (Technology W&P):
N type: GK-110N,GK-225N,GK-270N,GK-300N,GK-400N,GK-430N,GK-650N ,etc.
E type: GK-5E,GK-20E,GK-45E,GK-90E,GK-135E,GK-190E,GK-250E,GK-320E,GK-420E,GK-580E,etc.
F series (Technology Farrel)
F270L,F370L,F650L, etc.
XM-160,XM-20,XM-370,XM-650 ,etc.
The rubber mixers which we supply are the top level mixers in China industry, and also are used in many famous tyre factories around the world.
GK-E type (Most suitable for Master batch) Plastsea
Model Parameter | GK-45E | GK-90E | GK-E190 | GK-250E | GK-320E | GK-420E | GK-580E |
Total Volume of Mixer (L) | 47 | 87 | 195 | 250 | 320 | 450 | 580 |
Fill factor | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.7 | 0.65 |
Rotor speed (r/min) plastsea | 10-60 | 10-60 | 10-60 | 10-60 | 10-60 | 10-60 | 10-45 10-60 |
Ram Pressure (Mpa) | 0.5 | 0.55 | 0.54 0.58(Hyd.) | 0.51 | 0.62 | 0.55 | 0.55 |
Max production capacity (t/h) Plastea | 0.72 | 1.36 | 3.04 | 3.9 | 5 | 7.5 | 10.4 |
Compressed air pressure (Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
|
|
Air consumption (m3/h) | 92 | 140 | 432 | 423 | 604 | plastsea |
|
Cooling water pressure (Mpa) | 0.2-0.4 | ||||||
Cooling water consumption of main machine (m3/h) | 20 | 25 | 40/50 | 50 | 60 | 60 | 70 |
Steam pressure (Mpa) | 0.3 |
| 0.3 | ||||
Power of main motor (KW) | 280 | 520 | 1100 | 1320 | 1680 | 2x1250 | 2x1250 2x1250 |
Overall size(without motor) m | 3.9x2.4x3.7 | 4.6x2.3x4 | 5.9x3.4x5.6 | 6.1x4x6.1 | 6.6x4.6x6.5 | 6.7x4.6x6.3 | 7.5x4.8x7.5 |
Weight (without motor and gearbox) T | 8.5 | 11 | 26.5 | 33 | 38 | 50 | 60 |
|
|
|
|
|
|
|
|
Above parameter is only part. If you need more parameters and size of our rubber mixer, please contact us!
If you have such inquiry, We welcome you send us your requirement.
