Hot sale high quality batch-off cooler
- 100 Set / Sets per Month
- QINGDAO
- T/T
Product Details
Condition: | New | Type: | Tire Machine | Tire Machine Type: | Other Tire Machine |
Place of Origin: | Shandong, China | Brand Name: | PLASTSEA | Model Number: | XPG-600 XPG-800 XPG-900 |
Voltage: | 220v 380v 420v 440v | Power(W): | 110kw | Weight: | 11~34 TON |
Certification: | ISO CE | Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Professional manufacturer of rubber batch-off cooling machine
——PLASTSEA MACHINERY CO., LTD
1. Structure:
The film cooling line for overhead structure, rack vertical return, forced air cooling. The film cooling machine can be equipped with automatic pendulum glue, automatic laminated, weighing cutting, such as automatic sampling configuration.
2. Use:
This line will be mixed refine glue and refining rubber pressure out of the film coating isolation agent, cooling and laminated to deposit.
3. Sheet colling machine Features
(1). Integrating the operations of separant applying, air cooling, drying, cutting and wig-wag stacking, realizing continuous working and high-efficiency production
(2). Dipping slab for separant applying to achieve uniform applying and not polluting environment.
(3). Long air-cooling time brings about good cooling effect.
(4). Fixed-length cutting and adjustable cutting length.
(5). PLC technology and invertor adjustment are adopted, easy for full-process control.
4. Technical Parameters
Parameters/version | XPG-600-900 |
Lab specification | (4-12)*600-900 (mm) |
Front take-away conveyor belt max liner velocity | 400 (m/min) |
Rubber strip hanging barwoving speed | 0.117-1.17 (m/min) |
Axial fan | 0.37kw 5760m³/h |
Swing rang and frequency | 1.3m 10-16/min |
Rubber strip temperature after cooling | ≤+5°C |
≤room temperature+5°C | |
Speed-adjusting frequency motor of lifting swing edvice | XWD1.5-3-1/11 |
Speed-adjusting frequency motor of rubber swing edvie | XWD1.1-5-1/87 |
Rubber bar pitch | 160or101.6 |
Max hanging height of rubber strip | 1400mm |
1. Reply your inquiry in 24 working hours.
2. Customized design is available. UEM&UBM are welcomed.
3. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
4. Professional supplier: We are specialized in producing all kinds of machinery with competitive price and good quality.
5. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature.
As a professional machinery supplier,Plastsea Corp. was established by an experienced and professional team.It's located in Qingdao city which is the rubber&plastic industry center of China with the top level institute and university .
After several years developing,Plastsea has offered its excellent service and products to more than 30 countries in the world.
At present ,Plastsea focuses on Rubber and Tyre industries.Through joint-venture and cooperation methos,Plastsea has developed eight fabrication bases in China.The products cover internal mixer,twin-screw sheer,batch off cooling molds,tyre building drum,tyre bladder,tyre bladder mold,etc.
Payment terms
1. 30% T/T in advance, 70% should be paid before shippment.
2. L/C is also acceptable.
3. Any of your special requests is also welcome for discussion
Warranty
1. one year warranty.
2. free spare parts along with the shippment.
Welcome to visit our company and we can show you the machine in working condition:
If our products win your interest, please send us inquires and we will provide detailed information to you. We can also make machines according to your request.
