ZR Series Copeland Compressor Models ZR19M3E-TWD
US$ 1,085 - 1,285
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Thailand
Brand Name:
Copeland
Model Number:
ZR19M3E-TWD
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZR Series Copeland Scroll Compressor ZR160KC-TFD-522US$ 975 - 1,185MOQ: 1 Unit -
ZR Copeland Scroll Compressor ZR160KCE-TFD-522US$ 975 - 1,185MOQ: 1 Unit
-
15hp Hermetic Scroll Copeland Compressor ZR190KCE-TFD-522US$ 1,045 - 1,275MOQ: 1 Unit
-
20hp ZR Copeland Piston Compressor ZR250KC-TWD-522US$ 1,475 - 1,875MOQ: 1 Unit
-
R22 Copeland Compressor ZR Series ZR310KC-TWDUS$ 1,675 - 2,185MOQ: 1 Unit
Place of Origin
Thailand
Brand Name
Copeland
Model Number
ZR19M3E-TWD
Type
Refrigeration Compressor
Application
Refrigeration Parts
Certification
CE
Copeland Compressor Model
1,ZR11M3-TWD,ZR12M3-TWD,ZR16M3-TWD,ZR19M3-TWD
2,ZR11M3E-TWD,ZR12M3E-TWD,ZR16M3E-TWD,ZR19M3E-TWD
1,ZR11M3-TWD,ZR12M3-TWD,ZR16M3-TWD,ZR19M3-TWD
2,ZR11M3E-TWD,ZR12M3E-TWD,ZR16M3E-TWD,ZR19M3E-TWD
Type: Hermetic piston compressors
Producer: Copeland
Series: ZR
Model: ZR19M3E-TWD
Technical data
| Nominal motor power [HP]: | 15 | |
| Displacement [m³/h]: | 42,8 | |
| Sound pressure level : | 69 | |
| Gross/Net weight [kg]: | 130/119 | |
| Oil charge [dm³]: | 4,1 |
Electrical data
| Power supply [V/~/Hz]: | 1 5/8" | |
| Locked rotor current [A]: | 1 1/8" | |
| Max. operating current [A]: | 1 3/4" | |
| Winding resistance [Ω]: | 321/349 |
Connections
| milimeters | inches | ||
| Suction Rotolock valve connection: | 2 1/4" | ||
| Discharge Rotolock valve connection: | 1 3/4" | ||
| Suction connection with supplied sleeve: | 1 5/8" | ||
| Discharge connection with supplied sleeve: | 1 1/8" |
Capacity: R-22,R134A,R407C
Cooling capacity [kW]
| tc te | -20 | -15 | -10 | -5 | 0 | 5 | 10 | 15 |
| 20 | 22.91 | 27.23 | 32.42 | 38.61 | 45.92 | 54.46 | - | - |
| 25 | 21.09 | 25.47 | 30.65 | 36.74 | 43.87 | 52.15 | 61.70 | - |
| 30 | 19.43 | 23.87 | 29.03 | 35.01 | 41.95 | 49.96 | 59.16 | 69.67 |
| 35 | 17.90 | 22.38 | 27.50 | 33.37 | 40.12 | 47.85 | 56.69 | 66.76 |
| 40 | 16.43 | 20.96 | 26.03 | 31.78 | 38.32 | 45.76 | 54.23 | 63.84 |
| 45 | - | 19.54 | 24.57 | 30.18 | 36.50 | 43.65 | 51.74 | 60.89 |
| 50 | - | - | 23.05 | 28.52 | 34.62 | 41.46 | 49.16 | 57.85 |
| 55 | - | - | - | 26.76 | 32.63 | 39.15 | 46.46 | 54.66 |
| 60 | - | - | - | - | 30.47 | 36.67 | 43.57 | 51.29 |
| 65 | - | - | - | - | 28.10 | 33.97 | 40.46 | 47.68 |
Drawing:
Pictures:
