drywall vertical keel gypsum drywall metal stud
Installation
Drywall structure
Specification description
| Item | Description | Width(mm) | Hight1 (mm) | Hight2 (mm) | Thickness (mm) | Length |
| wall stud | 41,44,48,50,51,60, 64,70,75, 76,92,100. hight from 25mm to 50mm. | 22 | 22 | 0.3~ 0.6mm | 3000mm, 3660mm |
| 23 | 23 | 0.3~ 0.6mm | ||||
| 24 | 24 | 0.3~ 0.6mm | ||||
| 30 | 30 | 0.4~0.6mm | ||||
| 32 | 32 | 0.4~ 0.6mm | ||||
| 33.5 | 35.5 | 0.3~ 1.2mm | ||||
| 35 | 35 | 0.45~0.8mm | ||||
| 40 | 40 | 0.45~0.7mm | ||||
| 50 | 50 | 0.5~ 0.8mm | ||||
| track | 41,50,52,64,66,70, 75,76,92,93,100. hight from 25mm to 50mm. | 25 | 25 | 0.35~0.6mm | |
| 28 | 28 | 0.3~ 1.2mm | ||||
| 32 | 32 | 0.3~ 1.2mm | ||||
| 40 | 40 | 0.5~ 0.8mm |
Relevant specification for each market
1)Specification of South America market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 41*32 | 0.4--1 | 3050 |
| 64*32 | |||
| 76*32 | |||
| 92*32 | |||
| 92*41 | |||
| 100*35 | |||
| Track | 41*25--40 | 0.4--1 | 3050 |
| 64*25--40 | |||
| 76*25--40 | |||
| 92*25--40 | |||
| 100*25--40 | |||
| Corner bead | 32*32 | 0.3--0.5 | 3050 |
| Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Main channel | 38*12 | 0.4--0.8 | 3660 or any other length |
| 37*20 | |||
| Furring channel | 58*34*16 | ||
| 64*32*22 | |||
| 47*17 | |||
| 52*25*15 | |||
2)Specification of Malaysia market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| U channel | 41*23 | 0.3-0.5 | 2440, 2740, 3050 |
| 44*22 | |||
| 48*22 | |||
| 50*23 | |||
| 75*24 | |||
| Roof and Ceiling | |||
| Component name | Specificaion (mm) | Thickness (mm) | Length (mm) |
| C section | 75*34*36 | 0.7--1 | 3660--5800 |
| 100*50 | |||
| B batten | 58*35*23 | 0.5--0.8 | 3660-5800 |
| 65*32*26 | |||
| 84*30*32 | |||
| Furring Channel | 30*9 | 0.25-0.3 | 3660 |
| 34*11 | |||
3)Specification of Middle East market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*35/40 | 0.5--1 | 3000 |
| 70*32/35 | |||
| 75*35/40 | |||
| 100*35 | |||
| Track | 50*25--50 | 0.5--1 | 3000 |
| 70*25--50 | |||
| 100*25---50 | |||
| Ceiling | |||
| Component name | Spceification (mm) | Thickness (mm) | Length (mm) |
| Main channel | 38*10--12 | 0.38--0.5 | 3000 |
| Furring channel | 64*32*22 | ||
| 70*35*22 | |||
| 80*48*22 | 0.7 | 4000 | |
4)Specification of Eastern Europe market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*50 | 0.3--0.7 | 3000 |
| 75*50 | |||
| 100*50 | |||
| Track | 50*25--50 | ||
| 75*25--50 | |||
| 100*25--50 | |||
| Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Furring channel | 60*27 | 0.5--0.7 | 3000 |
| Wall angle / Track | 28*27 | 0.5--0.7 | 3000 |
5)Specification of Myanmar market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 75x35 | 0.4--0.6 | 2900 |
| 65x32 | |||
| Track | 76x25 | ||
| 66x25 | |||
| Roof and Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| C sectionC section | 75x34x36 | 0.7--1.5 | 5800 |
| 100x50x50 | |||
| B Batten | 64x24x24 | 0.4--0.6 | 5800 |
| 65x32x26 | |||
| Furring channel / C-line | 35x12 | 0.3--0.5 | 3960 |
| Main channel | 18x28 | 0.5--0.8 | 3050 |
| Furring channel | 50x17 | 0.4-0.5 | |
6)Specification of Thailand market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 75x35 | 0.4--0.55 | 2400, 3000 |
| 65x32 | |||
| Track | 76x25 | ||
| 66x25 | |||
| Roof and Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| C section | 75x34x36 | 0.7-1.5 | 6000 |
| 100x50x50 | |||
| B batten | 65x25x26.5 | 0.4-0.6 | |
| 65x32x26 | |||
| Furring channel / C-line | 35x12 | 0.3-0.5 | 4000 |
7)Specification of Philippines market
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*32 | 0.4--0.8 | 3000 |
| 64*32 | |||
| 75*35 | |||
| 92*35 | |||
| 100*35 | |||
| Track | 50*25--50 | 0.4--0.8 | 3000 |
| 64*25--50 | |||
| 75*25--50 | |||
| 92*25--50 | |||
| 100*25--50 | |||
| Roof and Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| C section | 100*50 | 0.7--1.5 | 3000 |
| 150*50 | |||
| Main channel | 38*12 | 0.5--0.8 | 3000 |
| Furring channel | 50*19 | 0.4--0.5 | 3000 |
8)Specification of Australia market
| All Australia products wil be made by G550 galvanized sheet with zinc coating 275g/m2 | |||
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 51x33.5x35.5 | 0.5--0.75 | 2700,3000 |
| 64x33.5x35.5 | 3600,4200 | ||
| 76x33.5x35.5 | 4800,6000 | ||
| 92x33.5x35.5 | |||
| Track | 52x32/28 | 0.5--0.75 | 3000 |
| 65x32/28 | |||
| 77x32/28 | |||
| 93x32/28 | |||
| MPW 10 H Stud | 12.5X40 | 0.3-0.5 | 3000-6000 |
| MPW 10 H Stud | 25X35 | ||
| MPW 10 U Kap | 15X25 | ||
| MPW 10 π Track | 55X25 | ||
| V-angle bead | 30X30 | ||
| L -angle bead | 30X6 | ||
| L-angle bead | 30X10 | ||
| L -angle bead | 30X13 | ||
| L -angle bead | 30X16 | ||
| J -angle bead | 30X10X13 | ||
| Z -angle bead | 30X10X10 | ||
| Z -angle bead | 30X10X6 | ||
| Roof and Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Main channel | 25x21 | 0.75 | 3600,4800,6000 |
| Furring channel | 51x38x28 | 0.5 | 2700,3000,3600,4800,6000 |
| 51x38x16 | |||
| C channel | 36x16 | 0.45 | 3000,3600 |
| Wall angle | 35x16x13 | 0.5 | 3000 |
| 35x28x20 | |||
| B batten | 94x42x40 | 0.55/0.75 | 4800,6000 |
Steel coils
Machine
Production lines
Loading
Factory
Sales office
Customer pictures
Certificates
Our Advantages:
(1). Design according to customers’ requirements
(2). Manufacture under complete quality control system---ISO9001
(3). Installation with instruction of experienced engineers
(4). Easy to assemble and dismantle
(5). Eco-friendly material: can be used for several times and can be recycled
(6). Shorter construction period, longer using time
(7). High strength and stiffness, high weight bearing.
Welcome to come to Guangzhou to Guangzhou Jianli for a visit
Guangzhou Jianli Newtype Partition Co., Ltd.
B402-B403, 8 Kesheng Road, Guangzhou Civilian Science& Technology Park, 1633 Beitai Rd., Baiyun Dist., Guangzhou, Guangdong, China (Mainland)
Website:
Website on : http://gzjlsra.en.
Sales manager:Jackie Wu
Tel:+86 13580514095
wechat:jackie6625
Viber:Jackie Wu
Skype:wzh0125
WhatsApp:+86 13580514095
