Platform Floor Steel Grating/Galvanized Welded Steel Grating Manufacturer

US$ 5 - 55 MOQ: 5 Square Meters

Key Specifications

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Grade:

Low carbon steel

Dimensions:

32*5

Hebei Jiuwang Metal Wire Mesh Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xin Gang

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, BS, DIN, GB, JIS

Grade Low carbon steel

Dimensions 32*5

Place of Origin Hebei, China

Brand Name JW

Model Number G325/40/100

Application Steel Walkway And Floor

Galvanized Welded steel grating manufacturer

Product details:

Model No.	G325/40/100
Bearing bar thickness (mm)	5
Bearing bar width (mm)	32
Cross bar diameter (mm)	6
Bearing bar pitch/distance (mm)	40
Cross bar pitch/distance (mm)	100
Surface treatment	GALVANIZED
Standard	China: YB/T4001.1-2007 UK: BS4592-1-1995 USA: ANSI/NAAMM(MBG531-88) Australia: AS1657-1985
Certificate	ISO9001

Other details:

Package	Safety package or naked
Delivery	Within 20-30 days after receiving the deposit
Payment terms	EXW: 100% T/T. FOB: T/T, 30% deposit, 70% balance payment before shipping. CIF: T/T, 30% deposit, 70% balance payment at the sight of copy of B/L.
HS code	7308900000
Price validity	Within 7 days

Common sizes of steel grating:

Item No.	Bearing Bar Pitch	Cross Bar Pitch	Specification of bearing bar load (Width x thickness)
Item No.	Bearing Bar Pitch	Cross Bar Pitch	20x3	25x3	32x3	40x3	20x5	25x5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
1	30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
3	60	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50		G253/60/50	G323/60/50	G403/60/50	G205/60/50	G255/60/50
